Help CenterRFID HF Reader
Related Products
Specifications
Work frequency 13.56MhzSupport ISO14443 or ISO15693, can read S50, s70, USB port
No need install driver.
HCT-HFR_700 serial contactless IC card reader is front-end device for development IC card or other RFID product and solution etc. it can use depend or embed into other machine. The feature is good performance, stability, compatibility.
Model |
HCT-HFR-700 |
Frequency |
13.56MHz |
Protocol |
ISO 14443A,ISO14443B,ISO 15693 |
Support Chip |
1.ISO14443A:Mifare_One(S50&S70)/UltraLight/Mifare_Pro ,ULtralight C |
O/S |
Microsoft Windows2000/XP/Vista/WIN 7 |
Port |
USB 2.0 |
Power |
USB power |
Indication lights |
Three colors LED,buzzer |
RFID antenna |
Antenna built in |
Support SAM |
Built two SAM slot |
Reading range |
ISO 14443A:6CM(depend on antenna structure and working environment ) |
Dimension |
100 *60 *12mm |
Weight |
100g |
Power dissipation |
5 mA (typical) standby |
Working temperature |
-25 - +85 °C |
Store temperature |
-40 - +125 °C |
Development language |
C++,VC,Java,C#,vb,,pb,Delphi |
Model details
|
HCT_HRF-700A |
HCT-HFR_702D |
HCT-HFR_700H |
ISO 14443A |
a |
|
a |
ISO 14443B |
|
a |
a |
ISO 15693 |
|
|
a |
