Help CenterNew and Super-sensitive EAS AM System for Retailers General Merchandise XLD-AM02
Related Products
-
Anti-theft Am Sensor Detection Eas System XLD-AM04NegotiableMOQ: 5 Sets -
Eas AM System,clothes Store Anti-shoplifting(XLD-AM03)NegotiableMOQ: 10 Sets
-
AM Anti-theft Gate With 58 KHz XLD-AM01NegotiableMOQ: 1 Set
-
Acoustic Magnetic System AM Antenna With 58k XLD-AM04US$ 450 - 600MOQ: 10 Sets
-
Eas AM System,clothes Store Alarm Door(XLD-AM03)NegotiableMOQ: 10 Sets
Quick Detail:
1. MONO antenna, working with a host (controller)
2. Detecting distance: 1m*2 soft tag, 1.4m*2(hard tag)
3. Material: import acrylic
4. Strong anti-jamming
5. DSP Board
6. Frequency: 58KHZ
Specifications:
Product Size |
1500*380*115 mm |
Material |
Imported Acrylic |
Frequency |
58KHZ |
Detecting range |
2m for soft tag ,hard tag can reach up to 2.8 m (On either of Detector) |
Thickness |
25 mm |
Electronic board |
DSP Board |
Detection area |
more than 95 percent |
Power |
15 W |
Electrical source |
AC(50~60hz)220V~245V |
Installation Type |
base type, line slot, embedded tube |
Description:
1. Technical Advantages: Imported Acrylic Material body, elegant appearance, strong aging esistance, durable. Among the detection antennas of the same kind, it has increased measurement range, strong anti-interference performance, applicable to various shopping places.
2. Automatic signal conditioning: the most advanced automated environmental monitoring program, auto-matching of system parameters, truly free from system adjustment.
3. Manual signal conditioning: capable of configuring the system manually in the complex field environment, strong adaptability.
4. Wireless synchronized signal technology: capable of selecting different synchronization values by adjusting the frequency synthesizer, the interference on the frequency is staggered, and the channel is more broad.
5. High-precision digital filtering technology: fourth-order digital filter technology,.
6. Multi-level filtering processing of signals, effectively improving the range and efficiency of tag detection.
7. Intelligent display technology: Various parameters can be displayed and both LED multifunction process.
8. Man-machine interactive design: Infrared Remote Control, simple operation, convenient and fast.
9. 100MHZ High speed DSP digital signal processing, super data processing performance to ensure system detection sensitivity and stability.
Main Advantages:
1. Most advanced signal processing (DSP) technology;
2. Self-adapting multichannel Frequency Hopping, 95% detection rates;
3. Strong anti-jamming capability;
4. Multiple anti-interference technologies;
5. Very professional and popular in Use in Fashionable Super store and Supermarket.
Application places:
Supermarket, super mall, retail store, shoes store, clothes store, harware store, sports shop, hat shop, glasses store, jewelry store, pharmacy, cosmetic store, etc.
General Information:
Place of Origin |
Shenzhen, China |
Brand Name |
Sunleader |
Model Number |
XLD-AM02 |
Certification |
ISO9001: 2008 |
