uhf rfid reader application inautomated parking system support ISO18000-6B/ ISO18000-6C
CF-RU5112 is a high performance UHF RFID integrated reader. It is designed upon fully self-intellectual property. Based on proprietory efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, anti-counterfeit and industrial production process control system.
Features
1. Self-intellectual property;
2. Support ISO18000-6B, ISO18000-6C(EPC C1G2) protocol tag;
3. 865~868MHz, 902~928MHz frequency band(frequency customization optional);
4. FHSS or Fix Frequency transmission;
5. RF output power up to 30dbm(adjustable);
6. 12dbi antenna optional with effect distance up to 10m*;
7. Support auto-running, interactive and trigger-activating work mode;
8. Low power dissipation with single +9 DC power supply;
9. Support RS232, RS485, Wiegand TCP/IP interface;
* Effective distance depends on antenna, tag and environment.
Parameter
1.Absolute Maximum Rating
ITEM |
SYMBOL |
VALUE |
UNIT |
Power Supply |
VCC |
16 |
V |
Operating Temp. |
TOPR |
-10~+55 |
°C |
Storage Temp. |
TSTR |
-20~+75 |
°C |
2.Electrical and Mechanical Specification
Under TA=25°C,VCC=+9V unless specified
ITEM |
SYMBOL |
MIN |
TYP |
MAX |
UNIT |
Power Supply |
VCC |
8 |
9 |
12 |
V |
Current Dissipation |
IC |
350 |
650 |
mA |
|
Frequency |
FREQ |
902 |
928 |
MHz |
3.Interface
Item |
Comment |
Red |
+9V |
Black |
GND |
Yellow |
Wiegand DATA0 |
Blue |
Wiegand DATA1 |
Purple |
RS485 R+ |
Orange |
RS485 R- |
Brown |
GND |
White |
RS232 RXD |
Green |
RS232 TXD |
Grey |
Trigger input(TTL level) |
Other Support
1.Come with completed English SDK,demo software,user manual and source code,and these documents will help you develop the software.
2.Provide free card or tag to help you do distance testing.
This reader mainly used for vehicle management in parking application,for this application,you can use a card holder to fixed card on the windshield,or you can directly stick a windshield tag on the surface of windshield.
