860~960mhz Uhf Long Distance Rfid Module

General Description

CF-MU903 is a high performance UHF RFID Reader Module. It is designed upon fully self-intellectual property. Based on proprietary efficient digital signal processing algorithm, it supports fast tag read/write operation with high identification rate. It can be widely applied in many RFID application systems such as logistics, access control, attendance system, anti-counterfeit and industrial production process control system.

Features

Self-intellectual property;

Protocol: Support ISO18000-6C(EPC C1G2) tag;

Frequency: 865~868MHz, 902~928MHz frequency band(customization optional);

Read range: >15m(connect with 12dBi antenna)

Identification: >50pcs Multiple tags

speed: >50pcs/s Tag identify

power supply: Low power dissipation with single +3.4V~+5V DC;

Interface: RS232,SPI,I2C and WG interface for option

Size: 28*25*3.5mm

Performance

High stability, and the air cooling heat dissipation, without external heat sink; Can continue work 24 hours X365 days; FHSS or Fix Frequency transmission;

Support

RSSI; 4 GPIO port(Two input two output); IPEX RFID connector supports external antenna;Firmware  upgrade online;

More detail: /productdetails.aspx?pid=480
