Hot Sale UHF RFID Bluetooth Handheld Reader With 3meters Reading Range
US$ 220 - 250
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Chafon
Model Number:
CF-H601
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen Hongkong
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Handheld Android RFID ReaderUS$ 104 - 109MOQ: 1 Piece -
0-60cm Equipment Assets Inventory UHF RFID ReaderUS$ 104 - 109MOQ: 1 Piece
-
Hand Held Outdoor Rfid Wristband Reader for SaleUS$ 220 - 250MOQ: 1 Set
-
3.5mm Audio Interface RFID UHF Rfid Reader on IosUS$ 104 - 109MOQ: 1 Piece
-
Android 4.22 Rfid Handheld Nfc Long Distance ReaderUS$ 265 - 525MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
Chafon
Model Number
CF-H601
Hot sale UHF RFID bluetooth handheld reader with 3meters reading range
Product Description
| Weight | 480g | ||
| Dimension | 138 x 66 x 31mm(Thin: 31, Thick: 34) | ||
| charging and discharging parameter | Input | 5.0±0.25V DC | |
| output | 5.0±0.25V DC | ||
| nominal capacity | 3000mAhlithium polymer battery (>500 charge cycles) | ||
| Standard Charge Circuit | <1A | ||
| Standard Charging method | CV(constant voltage5.0V)charging | ||
| charging time | ≤6 hours | ||
| max charging current | <1A | ||
| max discharge current | <1A | ||
| end-off voltage | 3.3V | ||
| Interface | Bluetooth HID & SPP | ||
| 1D Infrared | Reading Mode | CCD | |
| Resolution | 2500 | ||
| Scan Rate | 300 scan/sec | ||
| Symbologies | Code128, EAN-13, EAN-8, Code39, UPC-A, UPC-E, Codabar, Interleaved 2 of 5, ISBN/ISSN, Code 93, UCC/EAN-128, GS1 Databar,ITF-14 | ||
| Precision | ≥ 5mil(under the condition of PCS: 0.9,Code 39) | ||
| Scan Distance | Code128(10mil):30mm-285mm; Code39(5mil):90mm-195mm; Code39(10mil):50mm-325mm; EAN-13(10mil):60mm-265mm; EAN-13(15mil):65mm-350mm; | ||
| sensitivity | incline | ±65°@0°Roll and 0° Skew | |
| rotate | ±30°@0°Pitch and 0°Skew | ||
| declination | ±60°@0°Roll and 0° Pitch | ||
| outdoor scanning | proprietary technology-- able to read the code bar under sun light | ||
| current | maximum current | 100mA | |
| standby current | 45mA | ||
| RFID(optional) | Frequency | 13.56MHz/860-960Mhz | |
| Reading Mode | reading-writing or auto-induction just for Reading | ||
| Supported Standards | ISO14443A/EPC GEN2 | ||
| Working distance | >30mm | ||
| working current | <100mA | ||
| Max Power Dissipation | 0.33W | ||
| Environment | Operating temperature | 0℃~45℃ | |
| Storage Temperature | -10℃~ +45℃ | ||
| Humidity | 5% - 95% ( Non-condensing ) | ||
| Clip | LED display | 4LED to show charging and discharging active status and electrical quantity:2LED show the working mode of Bar codes and Bluetooth working mode | |
| Auto charging | Automatically charging without pressing any key when inserting into the interface by USB cable. | ||
| Auto Detect | Automatically detect whether to charge when inserting into the interface by USB cable. | ||
| priority of charge | Priority of charging mobile phone, then charging the internal battery. | ||
| UPS function | When external power supply breaks off, its internal battery with keep charging mobile phone. | ||
| battery overcharge protection | Dual hardware protection: >4.2±0.04V | ||
| Battery over discharge alarm voltage | HW: 2.8±0.1V & SW: <3.3V; Priority to enable software protection | ||
| Output Current Limiting Threshold | ≤ 1.2A | ||
| short-circuit protection | HW protection | ||
| Standard Configuration | Micro USB Cable | ||
| Left and right buckle | |||
| front buckle (two pieces with different height) | |||
| skid and scratch resistant cloth 2pcs | |||
| Warranty Card | |||
| Certification | |||
| Instruction Book | |||
| Options | 5V/2A & 5V/1A two separate output high-quality car charger (use cell phone charger for both mobile phone and back splint when indoor, and use car charger when outdoor. The car charger can also charges tablet PC. | ||
| Sling | |||
| AC charger | |||
| Cross Screwdriver | |||
| pocke | |||
Products Display :
Packaging & Shipping
Our Services
Company Information
FAQ
1.Are you manufacturer?
Yes, we are 10 years experience professional RFID hardware manufacturer.
Yes, we are 10 years experience professional RFID hardware manufacturer.
2.What is your mainly product?
Our products include RFID reader, RFID tag, RFID module and antennas,include 125KHz , 13.56MHz and 860-960MHz three frequency.
3.What is your advantage?
We are professional RFID hardware solution provider,
we have strong technical team can provide after sale technical support online,also can provide customized service.
4.How to place order to Chafon?
You can place order to us through Alibaba trade assurance order online.
We also can accept payment by TT,Western Union or Paypal.
