15dBi UHF RFID Linear Polarization Antenna

Name: 15dBi UHF RFID Linear Polarization Antenna
Brand: DAILY RFID
SKU: 140570444
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Brand Name:

DAILY RFID

Model Number:

rfid linear polarization antenna

Guangzhou Daily RFID Co., Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

Guangzhou / Hongkong

Delivery Detail:

Delivery time depends on order quantity.

Brand Name DAILY RFID

Model Number rfid linear polarization antenna

15dBi UHF RFID Linear Polarization Antenna

Our website is

Product Details:
Important performance
Support protocol	ISO18000-6C EPC Gen2 / ISO18000-6B
Working frequency	ISM 902MHz ~ 928MHz, Or 920MHz ~ 925MHz
Customization	860MHz ~ 960MHz
Working mode	FHSS or working mode of fixed frequency pulse transmitting set by software
Transmit power	20dBm ~ 30 dBm (set by software)
Read-Write performance
Read speed	The average read time for single card is less than 10ms per 64 bits
Read distance	8m ~ 15m (tag and environment dependent)
Write speed	8bits less than 30ms
Write distance	4m ~ 7m (tag and environment dependent)
Read prompt	Buzzer
Data Port interface
USB Port	Yes
RS232 Port	Yes
RS485 Port	Yes
Weigand Port	Weigand26/34
Trigger port	Yes
TCP/IP Port (RJ45)	Yes
Electric parameter
Power supply	DC+9V,4A
Power consumption	6W
Exterior and weight
Dimension	450mm×450mm×60mm
Weight	3700g
Working environment
Working temperature	-30°C~70°C
Programming
Programming language	VC / Csharp / Delphi / / VB / JAVA
