200 M Reading Range Parallax RFID Card Reader for Logistics Management
Negotiable
/ Set
1 Set(Min.Order)
- 50000 Set / Sets per Month
- Guangzhou / Hongkong
- T/T D/P D/A Credit Card PayPal
You May Like
-
Portable RFID Smart Card Reader Writer for Factory Management
-
Programmable Passive RFID Data Logger for Inventory Management with Special Offer
-
Active Directional Long Distance RFID Reader with Best Price by DAILY RFID
-
2.4GHz Active Long Read high gain rfid antenna
-
2016 NEWEST RFID Inventory Scanning System, Long Range RFID Handheld Reader
-
Passive RFID Tag 2.4ghz with Low Cost
Product Details
| Place of Origin | Guangdong, China | Brand Name | DAILY RFID | |
| Model Number | Parallax RFID Card Reader |
Product Description
200 M Reading Range Parallax RFID Card Reader for Logistics Management
Our website is .This 2.45GHz RFID active reader DL580 is designed for asset tracking. With its long read up to 100 meters, this active RFID reader is perfectly used in enterprise supply chain management to improve the efficiency of asset tracking and management.
Product Specifications:
| Important performance | |
| Working frequency | ISM 2.4GHz ~ 2.5GHz |
| Identifiy direction | Omni-directional or directional (antenna dependent) |
| Antenna | Connect 1 antenna through SMA |
| Standard matched antenna | Omni-directional antenna |
| RF Power Range | -20 dBm ~ 0 dBm (set by software) |
| Receiving Sensitivity | -90 dBm |
| Modulation | GFSK |
| Read-Write performance | |
| Read Mode | 1) Automatic identifying within effective area (Auto mode) 2) Reading after external trigger (Trigger mode) 3) Reading under software command (Master-slave mode) |
| Identify Tag Time | Less than 1ms when identify single tag |
| Anti-collision | Read up to 500 pieces of tags simultaneously |
| Read distance | 0 ~ 100 m adjustable For reader with RSSI function, the distance will be half the above distances |
| Buffer Capacity | 1000 tags data |
| Working Status Indication | Buzzer, LED indicator light |
| Communication performance | |
| Communication Speed | 1000kbps |
| Input and Output | 1 triggering input |
| Optional function | 2 Relay output, CAN, RSSI |
| Data Port interface | |
| RS232 Port | Yes |
| RS485 Port | Yes |
| USB Port | Yes |
| Weigand Port | Weigand26/34/42/50 |
| Ethernet | Yes |
| Electric parameter | |
| Power supply | DC+5V,1A |
| Exterior and weight | |
| Product size | 119 mm*100 mm*35 mm |
| Packing size | 300 mm*280 mm*90 mm |
| Gross weight | 900 g |
| Net weight | 250 g |
| Accessories | Standard matched antenna, DC 5V/1A adapter, power cable, RS-232 cable, USB cable, Ethernet cable |
| Working environment | |
| Working temperature | -20°C ~ 70°C |
| Storage temperature | -40°C ~ 85°C |
Competitive Advantages:
- Extensive experience, leading technology and innovation
- Provide one-top personalized products, data security and application solutions
- DAILY RFID has a professional design team, close to trend of world
- High quality and competitive price
- Customized based on your specific requirements
- Excellent after-sale service, guarantee commitments
- Cooperation with top-level partner
- Professional creates assurance
- Have our own manufacturing factory
- We can open a new mould for you, with your logo engraved on the current wristband tag. Or produce new tag completely with your design, more details please contact the sales.
We can design and develop RFID tags and RFID readers in different sizes and different shapes for your different requirements.For more info about RFID products please kindly visit our website http:// or mail to us,our sales will contact you as soon as possible.
-Best DAILY, Best RFID-
