Full Body Security X Ray Scanner JH-5010IIA

Main Features:

1. Detecting the full ranges:can inspect the foreign matter concealed inside or outside of human body, but X backscatter and millimeter wave detector can only inspect the foreign matter and metal concealed outside of human body.
2. Protection of personal privacy:uses mini dose of x-ray radiation technology without showing human privacy, but X backscatter detectors and millimeter-wave detectors show human privacy, a definite invasion of privacy.
3. High inspection efficiency:time per inspection needs less than 2 seconds, but inspection times of other various brands need more than 10 seconds,suitable for places with a large flow of people to detect uninterruptedly, but other detectors do not have this function.
4. Inspection of low dose NB:Dose per inspection is less than 0.05,

the Lowest inspection dose closely approximate to natural radiation.

Application:

1)     Detecting for enterprises and armies.

2)     Detecting for court, prison,Customs,GOV.

3)     Detecting for entering or exiting mines.

4)     Explosion-proof for detecting contraband at airport, railway station,subway.

5)     Anti-shoplifting for jewelry stores ,bank,precious metals.

Technical Specification:

1. Wire display: 40AWG (0.0787mm).
2. Spatial resolution :less than 1.0mm.
3. Displayer : 24' LCD,resolution 1920*1200.
4. Time per inspection : <3.5s.
5. Moving pavement speed : 0.2m/s.
6. Detecting dose : <0.05µGy.
7. Ambient temperature range: 0~ 104F.
8. Relative humidity range : 0~80%.
9. Atmospheric pressure range:86KPa~106KPa.
10. Image processing :Detail enhancement, super enhancement, spatial display,anti-color, contrast stretch, partial enhancement,pseudo color.
11. Image enlarge:Optionally scan parts,continuous zoom,magnification of 1-32 time.
12. Image storage:Automatic storage, Select the storage , Image retrieval ,Format conversion (bmp , jpeg ,tiff and so on).
13. USB interface makes your imaging external storage easily.
14. User management: User rights management add or delete user's account, operation privilege setting.
15. Auxiliary management :Time and date,people counting,working

chronograph,operation log,maintenance & diagnose ,X-ray beam Timer,

others Photograph,suspect information inputting,video recording.

Installation Data:

1)     Power :about 800W

2)     Voltage: 180V-240V

3)     Frequency: 50Hz/60Hz

4)     Weight : 650kg

5)     External dimension : 2600×2100×2600 mm

6)     Passage way dimension :2600×500×260 mm

7)     Operating temperature: 0-104F

8)     Storage temperature : -4-140F

Hardware systems:

Basic configuration:

²  the central control system,

²  data transmission systems,

²  data acquisition system,

²  circulation system, security

²  protection shield system,

²  leakage protection system,

²  protective bracket.

Optional configuration:

²  moisture-proof system,

²  UPS uninterruptible power supply systems,

²  dust control system,

²  corrosion protection system,

²  high temperature protection system,

²  Video guide shows system.

Software system:

Basic configuration:

²  WLP weak photon perspective systems,

²  WLC weak photon tomography systems,

²  single-image processing system,

²  safety interlocking brake system,

²  intelligent storage retrieval systems.

Optional configuration:

²  Remote management system,

²  intelligent inspection system,

²  user management systems,

²  face recognition systems,

²  automatic alarm systems,

²  identity RDIF identification systems,

²  multi-screen display system.
