6x6 reinforcing welded wire mesh

Galvanized  welded wire  Mesh

Opening

Wire Diameter

In inch

In metric unit(mm)

2" x 3"

50mm x 75mm

2.0mm, 2.5mm, 1.65mm

3" x 3"

75mm x 756mm

2.67mm, 2.41mm, 2.11mm, 1.83mm, 1.65mm

2" x 4"

50mm x 100mm

2.11mm, 2.5mm

4" x 4"

100mm x 100mm

2.0mm, 2.5mm

Technical Note:
1, Standard roll length: 30m; width: 0.5m to 1.8m.
2, Special sizes available at request.
3, Packing: in waterproof paper in rolls. Custom packing available at request

Specification List of Welded Wire Mesh

Opening

Wire Diameter(BWG)

In inch

In metric unit(mm)

1/4" x 1/4"

6.4mm x 6.4mm

22,23,24

3/8" x 3/8"

10.6mm x 10.6mm

19,20,21,22

1/2" x 1/2"

12.7mm x 12.7mm

16,17,18,19,20,21,22,23

5/8" x 5/8"

16mm x 16mm

18,19,20,21,

3/4" x 3/4"

19.1mm x 19.1mm

16,17,18,19,20,21

1" x 1/2"

25.4mm x 12.7mm

16,17,18,19,20,21

1-1/2" x 1-1/2"

38mm x 38mm

14,15,16,17,18,19

1" x 2"

25.4mm x 50.8mm

14,15,16

2" x 2"

50.8mm x 50.8mm

12,13,14,15,16

Technical Note:
1,Standard roll length: 30m;width: 0.5m to 1.8m
2,Special sizes available at request
3,Packing: in waterproof paper in rolls. Customed packing available at request

PVC Coated Welded Mesh (in 30m Length, Width of 0.5m-1.2m)

Mesh

Wire Gauge (BWG)

Inch

MM

1/2" x 1/2"

12.7mm x 12.7mm

16-21

3/4" x 3/4"

19mm x 19mm

16-21

1" x 1"

25.4mm x 25.4mm

15-20
