Home > Metallurgy, Mineral & Energy > Steel & Products > Steel Wire > Stainless Steel Wire(china Supply)

Stainless Steel Wire(china Supply)

Name: Stainless Steel Wire(china Supply)
Brand: Xinboyuan
SKU: 140541138
Availability: InStock

Anping Xinboyuan Wire Mesh Products Co., Ltd.

Stainless Steel Wire(china Supply) thumbnail-1

Stainless Steel Wire(china Supply) photo-1

US$ 1,000 - 3,000 MOQ: 1 Ton

Key Specifications

Get Latest Price

Standard:

AISI, ASTM, DIN, EN, GB, JIS

Grade:

Other, 300 Series, 201,301,304,316,316L,310

Wire Gauge:

0.05-20mm

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Standard AISI, ASTM, DIN, EN, GB, JIS

Grade Other, 300 Series, 201,301,304,316,316L,310

Wire Gauge 0.05-20mm

Length 4m

Application spring, screw, rope, steel brush, pin, metal mesh, etc

Certification ISO

C Content (%) 0.08

Si Content (%) 1.00

Place of Origin Hebei, China

Brand Name Xinboyuan

Model Number XBY-H0034

Specifications

high tensile strength stainless steel spring wire
1.Factory price
2.Customized size
3.fast delivery
4.Certificate:ISO

Specification

Wire Diameter(mm)	Tolerance(mm)	Max. Deviation Tolerance (mm)
0.020-0.049	+0.002/-0.001	0.001
0.050-0.074	0.002	0.002
0.075-0.089	0.002	0.002
0.090-0.109	+0.003/-0.002	0.002
0.110-0.169	0.003	0.003
0.170-0.184	0.004	0.004
0.185-0.199	0.004	0.004
0.200-0.299	0.005	0.005
0.300-0.310	0.006	0.006
0.320-0.499	0.006

Grade

TYPE	C	Si	Mn	P	S	Ni	Cr
AISI302	0.15	1.00	2.00	0.045	0.030	8.0-10.0	17.0-19.0
304	0.08	1.00	2.00	0.045	0.03	8.0-10.0	18.0-20.0
304HC	0.08	1.00	2.00	0.045	0.03	8.0-10.0	17.0-19.0
304L	0.3	1.00	2.00	0.045	0.03	9.0-13.0	18.0-20.0
316	0.08	1.00	2.00	0.045	0.03	10.0-14.0	16.0-18.0
316L	0.03	1.00	2.00	0.045	0.03	12.0-15.0	16.0-18.0
321	0.08	1.00	2.00	0.045	0.03	9.0-13.0	17.0-19.0
430	0.12	0.75	1.00	0.04	0.03	-----------	16.0-18.0
430F	0.12	1.00	1.25	0.06	0.15	-----------	16.0-18.0

Application

Supplying good elongation generatrix for other manufacturers in the lines of filament drawing, producing fine spring wire, acupuncture wire and pressed wire, etc.
