Mechanical Great-wall Dual Clipper JCK-120

Mechanical Great-wall Dual Clipper JCK-120 photo-1
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
YC
Model Number:
JCK-120
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang seaport
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hebei, China
Brand Name YC
Model Number JCK-120
Type Other, sausage production machinery

Specifications

1.sutiable for various plastic casings
2.suitable for wide range sausage diameter
3.sausage shows good quality and competitive







YC Mechanism Automatic Double Clipper JCK-120 is connected mechanically and electrically to the any vacuum stuffer or pneumatic stuffer. The voiding separator provides portions of precise weight, which are clipped as single sausages or rings. Trend- setting safety standards are guaranteed with the two-handed trigger operation required to start the first clip.



Advantages:
        Ranked as Top Leader in China in terms of productivity and equipment faults.
    Tough stainless steel Design construction guarantee extensive machine life.
    Ensures resistance to aggressive cleaning.
    Controlled electronically via a PLC and servo-frequency inverter.
    Easy touch means simple and convenient machine operation.
    Friendly user interface makes the machine control easier.
    Operator is quided intuitively through the flat menu structure with informative and can easily control the complete machine at the touch of a finger.
    Programs set of parameters easily managed screen and settings speed up product change rapidly.

Automatic Double Clipper JCSK-A built with the Japan Panasonic servo motor as the drive system, the man-machine interface from Taiwan and the Japan Mitsubishi PLC. It is designed with the state-of-the-art forced wire-feed mechanism, featuring precise and clear action.




Model
Clip Speed (times/Min)

Applicable Clipping

Casing Range
(mm)

Power
(KW)

Rated
Voltage
(V)

Weight
(Kg)

Dimensions
(mm)
JCSK-A
1-120
15-6/15-7/15-8/15-9
32-130
2.7
220
502
800*1150*1810
