High Quality Vegetable Cutter Machine/food Cutter

High Quality Vegetable Cutter Machine/food Cutter thumbnail-1
High Quality Vegetable Cutter Machine/food Cutter photo-1
US$ 1 - 9,999 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Hebei, China
Brand Name:
yuanchang
Contact Supplier Request Quote Chat Now
Hebei Yuanchang Food Mechanism & Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Hebei, China
Brand Name yuanchang
Model Number ZB80,ZB125,ZB200,ZB330,ZB420
Certification CE,ISO
Warranty ONE year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

vegetable cutter machine
1.stainless steel 304
2.80-420litre capacity
3.max cutting speed:4500r/min
4.lifter



                                                High quality Vegetable cutter machine/food cutter

                                                                                      High-Speed Meat Bowl Cutter



Specification:



Model Volume(L) Cutter Speed (r/min) Pot speed(r/min)       Discharger  Speed  (r/min)                                   Power(kw) Rated voltage(v)                   Weight(kg)

Dimensions

(mm)
ZB80 80 750/1550/3128 8/16 50 14 380 1020 1810*1100*1200
ZB125 125 200-4500 11/16 50 25.17 380 1690 2110*1300*1300
ZB200 200 300-4000 0-10 50 58.8 380 4500 3400*2400*1310
ZB330 330 300-3600 0-6 stepless speed 97.4 380 5000 3810*2900*1500
ZB420 420 128-3600 0-6 stepless speed 139.4 380 5800 3900*2950*1550

Note: The power of machine can be customized upon request.



Advantages:

1.all stainless steel construction

2.cutting,mixing function

3.Extra hard solid stainless steel bowl & vibration free

4.two types of knife: folding knife and moon knife    6 pieces/set

5.The most sanitary design for easy, fast clean-up.

6.Easy operation and low fault..

7.max cutting speed: 4500r/min

8.sizes: 80,125,200,330,420Litre capacity

9.lift device for auto feeding(200,330,420L capacity)







                                    High quality Vegetable cutter machine/food cutter

                                                   Vacuum Bowl Cutter



Specification:



Model
Volume (L)
Cutting Speed (r/min)
Pot Speed (r/min)
Discharger Speed (r/min)
Power(KW)
Cutter Quantity(Pc)
Rated Voltage
(V)
Vacuum Level
(Mpa)
Weight
(Kg)
Dimensions
(mm)
ZKZB-125
125
300-4200
0-10
Infinately variable drive(Speed gear-shift is also available upon request)
35.2
6
380
-0.085
2425
2160*1750*1300
ZKZB-200
200
400-4000
0-10
86.4
6
380
-0.085
4100
3280*2590*1500
 ZKZB-330
 330
360-3600
0-6
 102.4
 6
 380
-0.085
5000
3850*3000*1750
 ZKZB-420
 420
 360-3600
 0-6
 144.4
 6
 380
 -0.085
 5800
3940*3030*1850

 Note: The power of machine can be cusomized upon request.



Advantages:

1. High-graded SUS 304 stainless steel construction with 6 blade knife-headed Cutter.
2.Smooth surfaces giving the Cutter most sanitary design for easy and fast clean-up.
3.Innovative axle shaft design.
4.Automatic water feeding system (optional).

5.Superior quality solid stainless steel bowl attached with large diameter bearings & guarantees a smooth Vibration-free cutting.

6.Touch-Screen Monitor System (All movements - Loading/Unloading, Bowl cover, Knives & Bowl Speed, Vacuum system, Batch No, Time of process, Products temperature, Volume of water added, Fault diagnostics) by touch of a finger on Coloured LCD display.

7.Designed with observation windows and material filling hole.
8.Smooth control cut-mixing rotations and bowl rotations gives a wide range of programmes which can be used in every cutting process.
9.Low vibration level due to balanceable knife head & minimal noise drive system.
10.Vacuum Bowl Cutter sized from : 125, 200, 330, 420, 500 Litre capacity.







High quality Vegetable cutter machine/food cutterHigh quality Vegetable cutter machine/food cutter







 If you are interestd in the above machine, please invite us for further discussions.

We would be very pleased to hear your opinions soon.
