high quality sausage bowl Cutter machine for sale

Specifications

sausage bowl cutter machine
1.stainless steel 304
2.80-420litre capacity
3.max cutting speed:4500r/min
4.lift device





                                                                                      High-Speed Meat Bowl Cutter



Specification:



Model	Volume(L)	Cutter Speed (r/min)	Pot speed(r/min)	Discharger  Speed  (r/min)	Power(kw)	Rated voltage(v)	Weight(kg)	Dimensions (mm)
ZB80	80	750/1550/3128	8/16	50	14	380	1020	1810*1100*1200
ZB125	125	200-4500	11/16	50	25.17	380	1690	2110*1300*1300
ZB200	200	300-4000	0-10	50	58.8	380	4500	3400*2400*1310
ZB330	330	300-3600	0-6	stepless speed	97.4	380	5000	3810*2900*1500
ZB420	420	128-3600	0-6	stepless speed	139.4	380	5800	3900*2950*1550

Note: The power of machine can be customized upon request.



Advantages:

1.all stainless steel construction

2.cutting,mixing function

3.Extra hard solid stainless steel bowl & vibration free

4.two types of knife: folding knife and moon knife    6 pieces/set

5.The most sanitary design for easy, fast clean-up.

6.Easy operation and low fault..

7.max cutting speed: 4500r/min

8.sizes: 80,125,200,330,420Litre capacity

9.lift device for auto feeding(200,330,420L capacity)









                                                   Vacuum Bowl Cutter



Specification:



Model	Volume (L)	Cutting Speed (r/min)	Pot Speed (r/min)	Discharger Speed (r/min)	Power(KW)	Cutter Quantity(Pc)	Rated Voltage (V)	Vacuum Level (Mpa)	Weight (Kg)	Dimensions (mm)
ZKZB-125	125	300-4200	0-10	Infinately variable drive(Speed gear-shift is also available upon request)	35.2	6	380	-0.085	2425	2160*1750*1300
ZKZB-200	200	400-4000	0-10		86.4	6	380	-0.085	4100	3280*2590*1500
ZKZB-330	330	360-3600	0-6		102.4	6	380	-0.085	5000	3850*3000*1750
ZKZB-420	420	360-3600	0-6		144.4	6	380	-0.085	5800	3940*3030*1850

 Note: The power of machine can be cusomized upon request.



Advantages:

1. High-graded SUS 304 stainless steel construction with 6 blade knife-headed Cutter.
2.Smooth surfaces giving the Cutter most sanitary design for easy and fast clean-up.
3.Innovative axle shaft design.
4.Automatic water feeding system (optional).

5.Superior quality solid stainless steel bowl attached with large diameter bearings & guarantees a smooth Vibration-free cutting.

6.Touch-Screen Monitor System (All movements - Loading/Unloading, Bowl cover, Knives & Bowl Speed, Vacuum system, Batch No, Time of process, Products temperature, Volume of water added, Fault diagnostics) by touch of a finger on Coloured LCD display.

7.Designed with observation windows and material filling hole.
8.Smooth control cut-mixing rotations and bowl rotations gives a wide range of programmes which can be used in every cutting process.
9.Low vibration level due to balanceable knife head & minimal noise drive system.
10.Vacuum Bowl Cutter sized from : 125, 200, 330, 420, 500 Litre capacity.
