Hot Selling!! Portable High Efficiency SZL Series Package Steam Boiler 1-1.25-AII (Dongyue)

Hot Selling!! Portable High Efficiency SZL Series Package Steam Boiler 1-1.25-AII (Dongyue) thumbnail-1
Hot Selling!! Portable High Efficiency SZL Series Package Steam Boiler 1-1.25-AII (Dongyue) photo-1
US$ 42,000 - 56,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Natural Circulation
Usage:
Industrial
Contact Supplier Request Quote Chat Now
Dongyue Machinery Group Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QIngdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Natural Circulation
Usage Industrial
Structure Water Tube
Pressure Low Pressure
Style Horizontal
Fuel Coal-fired
Place of Origin Shandong, China
Brand Name Dongyue
Model Number 1-1.25-AII
Output Steam
Dimension(L*W*H) 5855x3550x3062
Weight 15T
Certification ISO9001/EC machine
After-sales Service Provided Engineers available to service machinery overseas

Specifications

coal fired steam boiler
1Spanish technology
2Good after machine service
3ISO9001/EC machine
4Germany hydraulic

  coal fired steam boiler

Product Features of SZL Series Package Steam Boiler

 1.Original horizontal tourbillion burn locule is applied on the boiler,which can improve thermal efficiency and lower waste concentration released notably.Somke emission concentration is less than 80mg/stere.,smoke blackness is less than Ringel-mann I level.It can be used for first class regions of the state. 2.Thermal efficiency is high,and the thermal efficiency of all kinds of boiler exceed ministry-issued standards over 5%?3.Water-tube boiler has a rational structure,which runs safely and reliably,and it has a long life-span. 4.Machining conical surface sealing structure is applied to air distribution device,average windpipe stucture is adopted in the wind room.This technology is protected by national patent. 5.The boiler is windely suitably for fule,such as bituminous coal class Ⅱand Ⅲclass . 6.the boiler has such features as compact struture,smallarea occupation.This serial of boiler is lied out single-storey,so the price of the boiler room can be decreased and the investment of the boiler room can be saved. 7.This series boiler is appraised as first-class product by Mechanical-Electronics ministry .They got the following award ,which are environment-protection product trusted by national users,national excellent energy-saving product,and excellent energy-saving product of shandong province. 8.Combustion apparatus and other energy-saving apparatus promoted by our country can be matched according to customer"s requiement.

Main Specifications of SZL Series Package Steam Boiler

boiler model

project

SZG

0.5-0.7-AII

SZL

1-1.25-AII 2

SZL2-1.25

/1.6-AII 2

SZL4-1.25

/1.6- AII 2

SZL6-1.25

/1.6- AII 2

SZL

6-2.5-AII

SZL8-1.25

/1.6-AII

rated steam capacity t/h

0.5

1

2

4

6

6

8

rated steam pressure Mpa

0.7

1.25

1.26/1.6

1.25/1.6

1.25/1.6

2.5

1.25/1.6

steam temperature °C

saturated

saturated

saturated

saturated

saturated

saturated

saturated

burning way

back-firing solid grate of double layer

chain grate

chain grate

chain grate

chain grate

chain grate

chain grate

applicable coal

AII , AIII

AII , AIII

AII , AIII

AII , AIII

AII , AIII

AII , AIII

AII , AIII

grate area m 2

0.93

1.29

3

4.6

7.23

7.23

8.6

the coal consumption at full load operation ( Kg/h )

86.2

153.3

322

649

839.4

973.6

1140

the body heating surface m 2

22.59

33.39

64.6

115.3

134.3

137.6

174.9

economizer heating surface m 2

/

10.78

18.48/37

37/55.4

55.5/92.5

130.8

73.93/130.8

exit gas temperature °C

190

175

170

165

165

170

160

effluent concentration of the smoke dust ( mg/Nm 3 )

<80

<80

<80

<80

<80

<80

<80

smoke blackness (Ringelmann level)



approved thermal efficiency %

77.3

77.3*

80.3

83.27

85.24

85.24

81.74

dimensions of biggest part for transportation (length x width x height) mm

2900x1800

x2980

4080x2150

x2862

5960x2690

x3462

6510x3130

x3462

7830x3340

x3462

7830x3340

x3462

8820x3340

x3462

weight of biggest part for transportation

6

15

20/22

28/30

40/42

42

45

overall dimensions of installed boiler(length x width x height) mm

3000x1800

x3000

5855x3550

x3062

7320x4963

x3862

8260x5197

x3862

10040x5332

x3862

10040x5332

x3862

11157x5332

x3862

Notes:1,The coal consumption at full load operation calculates to bituminous coal class II(dw=21320KJ/Kg) The items used*above refer to designed efficiency.

2 ,If the main specifications noted have changed,youcan refer to ex-work technical documents.

Products show

Hot selling!! portable high efficiency SZL Series Package Steam Boiler 1-1.25-AII (Dongyue)Hot selling!! portable high efficiency SZL Series Package Steam Boiler 1-1.25-AII (Dongyue)Hot selling!! portable high efficiency SZL Series Package Steam Boiler 1-1.25-AII (Dongyue)Hot selling!! portable high efficiency SZL Series Package Steam Boiler 1-1.25-AII (Dongyue)Hot selling!! portable high efficiency SZL Series Package Steam Boiler 1-1.25-AII (Dongyue)
