Specifications
1.CE,ISO9001,ASMEpct structure,energy-saving
3.simple installation
4.unpolluted
5.fuel burning abundant
All the friends from home and abroad are warmly welcome to visit !!
1.The reason for your choosing
Product Features of WNS,SZS Series Oil(Gas)-fired Boiler: 1,It is of the following features,such as full-auto-running,safety and reliability,varuous of control and protection device makes steam pressure,water temperature and combustion system are all automatic control with easily operate,save labour and raise the serviceability.Hot water boiler have program-controlled,temperature-controlled and time-controlled. 2,Equipped selectiy with import burner,the yuel can be full burned with greatly save energy effect.It can conform with the demanding regions. 3,Full-closed structure of the boiler and with features of smalless,noiseless,no pollution,good-looking and cleaniness. 4,Compact structure,small area occupation and easy to be installed.
2.Boiler data
WNS/LNS Series Full-automatic Oil(Gas)-fired Steam Boiler | ||||||||
|
boiler model items |
WNS 0.5-1.0-Y(Q) |
WNS 1-1.0-Y(Q) |
WNS 2-1.0-Y(Q) |
WNS 2-1.25- Y(Q) |
WNS 4-1.25- Y(Q) |
WNS 6-1.25- Y(Q) |
WNS 0.2-0.7- Y(Q) |
WNS 0.35-0.7- Y(Q) |
rated steam capaciry t/h |
0.5 |
1 |
2 |
2 |
4 |
6 |
0.2 |
0.35 |
rated working pressure Mpa |
1.0 |
1.0 |
1.0 |
1.25 |
1.25 |
1.25 |
0.7 |
0.7 |
feed water temperature °C |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
steam temperature °C |
184 |
184 |
184 |
194 |
194 |
194 |
170 |
170 |
the boiler heating surface m 2 |
14.3 |
28.08 |
59.13 |
58.3 |
105 |
166.7 |
6.22 |
9.15 |
design fuel |
light diesel oil |
light diesel oil |
light diesel oil |
light diesel oil |
light diesel oil |
light diesel oil |
light diesel oil |
light diesel oil |
designed effciency % |
82.7 |
84.77 |
86 |
90 |
88 |
88 |
85 |
85 |
combustion consumption ( kg/h ) |
37.6 |
73.4 |
143 |
143 |
283 |
424 |
14.1 |
23 |
burn |
import |
import |
import |
import |
import |
import |
import |
import |
The boiler may be use heavy oil,residual oil,gas and natural gas. It must be noted when contrast is concluded. | ||||||||
DONGYUE Machinery Group----Your best choice !!
Dongyue Machinery Group has always been adhering to the management idea of"Integrity, Innovation,Harmony, Security,Altruism",strive to produce highest quality products, built and completed management and quality control system.With broad domestic and international sales network and excellent after-sales service team, we gain the initiative in the fierce market competition, “Dongyue” brand reputation is famous in domestic and international market
.
"Approaching perfection Pursuing Prominence", "Dongyue Machine " is your best option
