Push-pull exhaust fan technique

FOB Price

US$ 200 - 250 / Unit

57 Units(Min. Order)

Port qingdao
Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Electric Current Type	AC	Mounting	Wall Fan
Blade Material	Stainless Steel	Place of Origin	Shandong, China
Brand Name	dalifang	Model Number	ETXS1250
Voltage	220	Power	1.1
Air Volume	35000	Speed	439
Certification	CCC, CE	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Banner

Product Description

Push-pull Exhaust fan Technique

Fan size: 1380mm×1380mm×450mm
Frame:
Hot galvanized sheet, high anti-corrosive durability, sheet thickness1.0mm,
zinkthickness 275g/M2
Motor:
Simens motor, Other motor accordingly, CE certificate
Motor technical data: 1.1 Kw 380 V 50 Hz three phase
Motor RPM: 1440r/min
Noise: low than 65db
Blade :
diameter: φ 1270 mm
Blade No.: 6
Blade material: Mirror face stainless steel, avoid dust accumulation
Blade RPM: 460r/min
Blade instruction:
Weight difference between blades is less than 0.5k,blades will go through
balance test after assembled which can assure steady running and even
airflow.
Shutter :
Centrifugal system opening, spring close system, shutter can be opened at
90 degree.
Shutter No.: 10
Thickness of shutter : 1.5 mm , others 0.8 mm
others:
Belt: Mistuboshi belt
Housing: galvanized
Airflow: 44000m3/h

Specification

Model Specifications	Blade Diameter (mm)	Frequency (Hz)	Motor rotational speed (rpm)	Air flow (m³/h)	Import power(W)	Rated voltage(V)	Height(mm)	Width (mm)	Thickness(mm)
DLFP-1000	910(36in)	50	≥1400	35000	750	380	1000	1000	450
DLFP-1380	1270(50in)	50	≥1400	48000	1100	380	1380	1380	450
