CE/ Eurovent Certificated Rotary Wheel Heat Exchanger for Sale

Beijing Holtop Artificial Environment Technology Co., Ltd. Gold Verified Supplier
5Yrs
CE/ Eurovent Certificated Rotary Wheel Heat Exchanger for Sale thumbnail-1
CE/ Eurovent Certificated Rotary Wheel Heat Exchanger for Sale photo-1
US$ 100 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Place of Origin:
Beijing, China
Brand Name:
HOLTOP
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Place of Origin Beijing, China
Brand Name HOLTOP
Model Number HRT500-5000; HRS500-5000
Structure Other, rotary heat exchanger
Liquid Flow Rate 1000-100000CMH
Maximum Working Pressure 2000 Pa
Voltage 380V, 220V/380V
Weight 42-2100KG
Dimension(L*W*H) 500*500-5000*5000 MM
Power(W) 0.09KW---1.1KW
Certification CE, Other, CE, Eurovent
Warranty 1 years
After-sales Service Provided No overseas service provided

Specifications

CE/ Eurovent certificated
High energy recovery efficiency
Wide application
Heat&moisture recovery
Total and sensible type

CE/ Eurovent certificated rotary wheel heat exchanger for sale

CE/ Eurovent certificated rotary wheel heat exchanger for sale

Specifications of rotary heat exchanger

1.Wide range diameter: 500-5000mm
2.Made of aluminum coating 3A molecular sieve
3.Double Sealing System
4.Eurovent and CE certified

5. 3A molecular sieve coating for total heat type.

6. Both sensible and total type are available.

7.saving Installation space


Working principle of  Eurovent certified 3A molecular sieve ERV rotary  exchanger



The aluminum covering 3A molecular sieve rotor diameter 500-5000mm hygroscopic heat wheel  is composed of alveolate heat wheel, case, drive system and sealing parts. The exhaust and outdoor air pass through half of the wheel separately, when the wheel rotates, the heat and moisture are exchanged between the exhaust and outdoor air. The energy recovery efficiency is up to70% to 90%.

CE/ Eurovent certificated rotary wheel heat exchanger for sale







Professional Selection Program for rotary heat exchanger to mare sure accurate selecting.

We have developed a calculation program for simple selection of a rotary heat exchanger model. It can not only be used as a single design selection program, but can also be combined into your program by DLL. We can add it to your program upon your request, too. Please contact us for the selection program.



Selection Chart



Specifications and dimensions of rotary heat exchanger

Model        Rotor diameter(mm)Wheel length(mm)Wheel width(mm)Wheel height(mm)Vot./HzPower(Kw)Kg
HRT-500500600340600380v/50Hz0.0942
HRT-600600700340700380v/50Hz0.0959
HRT-700700800340800380v/50Hz 0.0971
HRT-800800900340900 380v/50Hz 0.0982
HRT-90090010303401030 380v/50Hz 0.09102
HRT-1000100011303401130 380v/50Hz 0.09130
HRT-1100113012303401230 380v/50Hz 0.09151
HRT-1200123013303401330 380v/50Hz0.18169
HRT-1300133014303401430 380v/50Hz0.18190
HRT-1400143015303401530 380v/50Hz0.18205
HRT-1500153016303401630 380v/50Hz0.18220
HRT-1600163017303401730 380v/50Hz0.18239
HRT-1700173018303401830 380v/50Hz0.25266
HRT-1800183019303401930 380v/50Hz0.25293
HRT-1900193020303402030 380v/50Hz0.25320
HRT-2000203021303402130 380v/50Hz0.25370



Model         Rotor diameter(mm)Wheel lengt(mm)Wheel width(mm)Wheel height(mm)Vot./HzPower(Kw)Weight(Kg)

HRT-2200

2230

2400

340

2400

 380v/50Hz

0.37

420

HRT-2400243026003402600 380v/50Hz0.37500
HRT-2600263028003402800 380v/50Hz0.37570
HRT-2800283030003403000 380v/50Hz0.37860
HRT-3000303032003403200 380v/50Hz0.55950
HRT-3200323034003403400 380v/50Hz0.551039
HRT-3400343036003403600 380v/50Hz0.551110
HRT-3600363038003403800 380v/50Hz0.551220
HRT-3800383040003404000 380v/50Hz0.551360
HRT-4000403042003404200 380v/50Hz0.751500
HRT-4200423044003404400 380v/50Hz0.751645
HRT-4400443046003404600 380v/50Hz0.751750
HRT-4600463048003404800 380v/50Hz1.11830
HRT-4800483050003405000 380v/50Hz1.11980
HRT-5000503052003405200 380v/50Hz1.1

2100





Application of rotary heat exchanger



Rotary heat exchanger (wheel) is mainly used in building ventilation or in the air supply/discharge system of air conditioning equipment. The wheel transfers the energy (cold or heat) contained in exhaust air to the fresh air supplied to indoor. It’s one important equipment and key technology in the field of construction energy-saving.



Rotary heat exchanger can built in air handling unit(AHU)as a main part of the heat recovery section. Usually
side panel of the exchanger casing is unnecessary, except that bypass has been set in AHU.







About Beijing Holtop Artificial Environment Technology Co., Ltd

 1). Founded in 2002, Holtop is the leading and biggest Heat Recovery Ventilator manufacturer in China specializing in the   production of air to air heat recovery equipments, its product range mainly covers:

 1) Heat & Energy Recovery Ventilators.

 2) Rotary & Plate Heat Exchangers.

 3) Air Handling Units.



 2) Covering an area of more than 30,000 square meters and annual production ability of heat recovery equipment reaches 100,000 sets, Holtop owns numeral control machines, national approved labs, and has successfully passed the certifications of ISO9001, ISO14001, OHSAS18001, CE and EUROVENT.



 3) Due to good quality and best service, Holtop wins cooperation with many big brands like Midea, LG, Hitachi, McQuay, York,Trane and Carrier, etc.,details as below. What is more, Holtop is the qualified supplier for Beijing Olympics 2008 and Shanghai World Exposition 2010.

CE/ Eurovent certificated rotary wheel heat exchanger for sale

 A View to HOLTOP Factory.



Our Service Promise

1) Repy your enquiry within 24 hours.

2) Best quality and service.

3) Experienced  sales manager answer all your questions smoothy in English.

4) Can offer professional technical support to clients.

5) Exclusive and unique solution can be provided by our experienced engineer.

6) Special discount will be offered to you.



More information, pls feel free to contact sales manager  Mr. Jack Chen, or visit website:



Thanks for your visiting our website and wish you good business!
