Double Acting Hydraulic Cylinder With Brackets and Tie Rods
US$ 5 - 2,000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Power:
Hydraulic
Maximum Stroke:
3000mm
Place of Origin:
Shandong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cheap and Best Qualty of Hydraulic RamUS$ 30 - 5,000MOQ: 5 Pieces -
Good Price Best Quality Double Acting Welding Hydraulic CylinderUS$ 50 - 200MOQ: 5 Pieces
-
Different Type Good Price Hydraulic CylindersUS$ 30 - 5,000MOQ: 5 Pieces
-
Good Price /best Quality Hydraulic Cylinder in ChinaUS$ 30 - 5,000MOQ: 5 Pieces
-
Four Tie Rod Hydraulic Cylinder be Used Agricultural MachineUS$ 30 - 3,200MOQ: 5 Pieces
Power
Hydraulic
Maximum Stroke
3000mm
Place of Origin
Shandong, China
Model Number
YG
Brand Name
H&H
Double acting hydraulic cylinder with brackets and tie rods
1. Double acting single piston rod;2. Rated pressure: 7-14Mpa;
3. The temperature of medium: 10-80C; 4. Four tie-rods.
Usages and features:
YG series light hydraulic cylinder is a kind of dual acting single piston rod hydraulic cylinder which is designed by our company according to international and national standard. Four-tie rod structure, applied to middle & low working pressure. Two ends are both equipped with a cushioning, act sensitively and lightly, easy to install. Main applied to the rates pressure Pn<=14MPa, medium temperature around 80 of all kinds machinery and equipments.
Mounting way:
| Code | Form | Symbol |
| 1 | basic form | - |
| 2 | head fixed with flange | f |
| 3 | end fixed with flange | F |
| 4 | vertical to axis foot type | G |
| 5 | middle fixed with pendulum shift | B |
| 6 | end with single earring | S |
Feature:
| working pressure | 7~14Mpa |
| proof pressure | 21Mpa |
| transmission medium | general mineral hydraulic oil |
| start-up pressure | <=0.3Mpa |
| medium temperature | (-10,80) |
Cushioning way:
| Code | Cushioning form |
| B | two ends with cushioning |
| R | rod end with cushioning |
| H | end with cushioning |
| N | without cushioning |
Max stroke:
| Bore(mm) | Φ40 | Φ50 | Φ63 | Φ80 | Φ100 | Φ125 | Φ140 | Φ150 | Φ160 |
| Smax(mm) | 1200 | 1200 | 1600 | 1600 | 2000 | 2000 | 2000 | 2000 | 2000 |
