Help CenterThreaded Ended Hydraulic Cylinder
US$ 5 - 2,000
MOQ: 10 Pieces
Key Specifications
Get Latest Price
Standard or Nonstandard:
Standard
Structure:
Piston Cylinder
Power:
Hydraulic
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Good Quality Best Selling Small Hydraulic Cylinder for Agriculture TrailerUS$ 100 - 2,000MOQ: 10 Pieces -
China Manufacturer Hot Sale Best Selling Hydraulic Cylinder PriceUS$ 100 - 2,000MOQ: 10 Pieces
-
China Manufacturer Singel Acting Small Hydraulic Lift CylinderUS$ 100 - 2,000MOQ: 10 Pieces
-
China Manufacturer Multi Stages Professional Mini Hydraulic CylindersUS$ 100 - 2,000MOQ: 10 Pieces
-
Good Quality Best Selling Professional Double Acting Hydraulic CylinderUS$ 100 - 2,000MOQ: 10 Pieces
Standard or Nonstandard
Standard
Structure
Piston Cylinder
Power
Hydraulic
Body Material
Steel
Maximum Stroke
7000mm
Shaft Diameter
50mm
Place of Origin
Shandong, China
Model Number
HCWD
Brand Name
H&H or OEM
Double ended with clevis hydraulic cylinder
Usages and features:
tie rod hydraulic cylinder is a kind of dual acting single piston rod hydraulic cylinder which is designed by our company according to international and national standard. Four-tie rod structure, applied to middle & low working pressure. Two ends are both equipped with a cushioning, act sensitively and lightly, easy to install. Main applied to the rates pressure Pn<=14MPa, medium temperature around 80 of all kinds machinery and equipments.
Mounting way:
| Code | Form | Symbol |
| 1 | basic form | - |
| 2 | head fixed with flange | f |
| 3 | end fixed with flange | F |
| 4 | vertical to axis foot type | G |
| 5 | middle fixed with pendulum shift | B |
| 6 | end with single earring | S |
Feature:
| working pressure | 7~14Mpa |
| proof pressure | 21Mpa |
| transmission medium | general mineral hydraulic oil |
| start-up pressure | <=0.3Mpa |
| medium temperature | (-10,80) |
Cushioning way:
| Code | Cushioning form |
| B | two ends with cushioning |
| R | rod end with cushioning |
| H | end with cushioning |
| N | without cushioning |
Max stroke:
| Bore(mm) | Φ40 | Φ50 | Φ63 | Φ80 | Φ100 | Φ125 | Φ140 | Φ150 | Φ160 |
| Smax(mm) | 1200 | 1200 | 1600 | 1600 | 2000 | 2000 | 2000 | 2000 | 2000 |
