Product Details
Condition: | New | Type: | Separating Plant | Place of Origin: | Henan, China |
Brand Name: | Tongxin | Model Number: | XZS | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
our company has 20 years of producing 4000 companies ,and we service for more than 4000 companies at home and abroad .
Rotary vibrating screen (contact material part is stainless steel)
Features
v Small size, easy moving and space saving
v High screening efficiency- do not mesh plug and powder fly, screen up to 500 mesh(0.028mm)
v Screen mesh changing easy, simple, convenient cleansing, fast network for only 3-5 minutes
v Automatic discharge of impurities and coarse materials, continuous operation
v Can reach a maximum five-deckmachines, the use of the three-deck proposal
v Accord with ISO9001:2008 and CE certification
Technical parameter
Model | Diameter of Screen Surface | Effective Screening Area | Construction | Measuring Range | Deck | Power |
(mm) | (m2) | (mm) |
| (kw) | ||
XZS-600 | 560 | 0.2281 | v All material contact parts are made of stainless steel v Complete machine is made of carbon steel | Screen up to 0.028mm | 1-5 | 0.55 |
XZS-800 | 760 | 0.4183 | 1-5 | 0.75 | ||
XZS-1000 | 950/970 | 0.6359 | 1-5 | 1.1 | ||
XZS-1200 | 1130 | 0.9499 | 1-5 | 1.5 | ||
XZS-1500 | 1470 | 1.5386 | 1-5 | 2.2 | ||
XZS-1800 | 1770 | 2.2687 | 1-3 | 3.0 | ||
XZS-2000 | 1886 | 2.7922 | 1-3 | 3.7 |
Note: This is only for reference and products specification should be studied from the real products provided
Applicable Industry
v Chemical industry: resin pigment, medicine, grease, paint, palette, etc.
v Abrasive material and ceramic industry: building sand, mica, alumina, abrasive, refractory material, slurry, etc.
v Food industry: sugar, salt, alkali, gourmet powder, starch, milk powder, yeast powder, pollen, food additive, bean milk, juice, etc.
v Paper-making industry: coated slurry, exhaust liquid, paper making liquid and waste water reclamation, etc.
v Metallurgy and mining industry: quartz sand, ore, titanium oxide, zinc oxide, etc.
v Mechanical industry: casting sand, powder metallurgy, electromagnetic material and metal powder, etc.
Below are the pictures of the rotary vibrating screen ,only for reference .
The certificates of our factory
Here are the pictures of our factory ,welcome to visisted our factory from all over the world .
our customers visisted our factory .
Dear friends ,If you are interested in our product ,please fell free to contact us .
