Mini Vibration Sand Sieving Machine

Mini Vibration Sand Sieving Machine thumbnail-1
Mini Vibration Sand Sieving Machine photo-1
US$ 1,199 - 9,799 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Circular
Application:
Other, chemical,food,metal
Contact Supplier Request Quote Chat Now
Zhengzhou Hento Machinery Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao or as customers' request
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Circular
Application Other, chemical,food,metal
Place of Origin Henan, China
Brand Name HENTO
Model Number HTO-XZS-600
Voltage can be changed as customers' need
Power(W) 0.55/0.75/1.1/1.5/2.2/3.0/3.7
Dimension(L*W*H) On the specification
Weight On the specification
Certification CE SGS TUV
Warranty 2 years guarantee period
After-sales Service Provided Engineers available to service machinery overseas

  Mini Vibration Sand Sieving Machine





1.Machine introduction of Mini Vibration Sand Sieving Machine

Sand sieving machine  use one set vertical vibration motor as the source of vibrating screen, equip eccentricity hammer on the both sides of motor ,circumrotate to level, upright and incline movement, then pass these three movement to the surface of the screen .Adjust the phasic angle on the both sides of the top and bottom to change the movement orbits of the surface screen



Scope of application



Chemical industry: resin, pigment, industrial medicine, cosmetic, coatings, Chinese medicine power;
Food industry: sugar powder, starch, salt, rice noodles, milk powder, soybean milk, egg powder, sauce, syrup;
Metal, metallurgy mining industry:aluminum powder, ceruse, copper powder, ore alloy powder, welding rod powder, dioxide manganese, electrolyse copper powder, electo magnetism materials, rubbing powder, fire-proof material, kaolin, lime, alumina, heavy calcium carbonate, quartz;
Social pollution disposed:disposed oil, disposed water, disposed dye waste water,assistant detergent, active carbon.




2.Technical parameters of  Mini Vibration Sand Sieving Machine

Model

HTO- XZS-600

HTO- XZS-800

HTO- XZS-1000

HTO- XZS-1200

HTO- XZS-1500

HTO- XZS-1800

HTO- XZS-2000

Effective diameter for sieving (mm)

φ540

φ730

φ900

φ1100

φ1400

φ1700

φ1886

Effective sieving area(m2)

0.2281

0.4183

0.6359

0.9499

1.5386

2.2687

2.7922

Screen mesh size

2——500 mesh

number of layers

1-5

1-5

1-5

1-5

1-5

1-3

1-3

PowerKW

Vibrating motor

0.55

0.75

1.1

1.5

2.2

3.0

3.7

Common motor

0.75

1.1

1.5

1.5

2.2

2.2

3.0

Mini Vibration Sand Sieving Machine
