Hot Sale Industrial Stainless Conical Fermenter
1. Machine introduction of stainless conical fermenter
Beer fermentation tank is used for the fermentation of beer and wine storage, it is mainly composed of fermentation tank and seeds tank, they are attached to each raw material (medium) modulation, steaming, sterilization and cooling equipment, ventilation adjustment and aseptic equipment, as well as the agitator and so on. The fermentation tanks mainly undertake the product production tasks. Seed tank is mainly to ensure that the necessary bacteria fermentation tank culture dimension for the purpose.
2. Machine features of stainless conical fermenter
1. Capacity: 300~20, 000L.
2. Material: SUS 304 or 316.
3. Cylindercone bottom shape and dished top head. Beautiful design, no dead corner for cleaning.
4. Finishing: 2B, mat or mirror polishing (Roughness inside: Ra≤0.22μm ; outside: Ra≤0.4μm ).
5. Dimple jacket. Insulation: PU foam jacket on the side and bottom (50~80mm)
6. High quality material. The quality of stainless steel is very important in beer production. We manufacture with high quality stainless steel from famous steel company (chemical composition available).
3. Technical specification of stainless conical fermenter
| Inner surface | S.S.304,WELL POLISHED,polishing precision≤0.4µm,THK:2-4mm |
| Outside surface | S.S.304,frosted or mirror,THK:1.5-3mm |
| Top shape | Seal head or conical head |
| Conical degree | 60-90°c |
| Manhole location | Side upward/side/flanged |
| Insulation | Material:PU,THK:50-100mm |
| Cooling jackets | DIMPLED cooling jackets at bottom and side wall. |
| Spray ball | Located in the center of inside of the tank |
| Pressure | 0.2MPa |
| Thermometer | Bi-metal thermometer |
| Legs | 3/4 round legs,can designed to be adjustable |
| The ratio of working volume to gross volume | 4/5 |
| Operational method | Automatic or manual |
| Technology processing | Argon-arc welding,well weld in double sides. |
4. Contact information of stainless conical fermenter
If you need further information, please contact us freely, we will do our best to cooperate with you.
