Specifications
500w vertical wind tunnel, low rpm, domestic wind generator 500wlow noise
high safety
vertical axis small wind generator
500w vertical wind tunnel, low rpm, domestic wind generator 500w
Parameter:
| Model | JFVC-500W |
| diameter of wind wheel (m) | 1.8 |
| material of blades | Fiberglass-Reinforced Plastics |
| blades number | 5 |
| blades length (mm) | 1650 |
| blades width (mm) | 410 |
| RPM (r/min) | 80 |
| rated wind speed (m/s) | 12 |
| start up wind speed (m/s) | 2 |
| working wind speed (m/s) | 3-25 |
| survival wind speed (m/s) | 40 |
| generator style | 3-phase AC PMG |
| protection grade of generator | IP54 |
| material of generator case | cast iron |
| rated power (w) | 500 |
| the max. power (w) | 550 |
| rated voltage (VDC) | 24/48 |
| the height of tower (m) | 6 |
| guy cable tower type (mm) | 96*6 |
| controller and inverter | advanced wind & solar hybrid controller and pure sine wave inverter |
| battery reference | 12V100ah, 2pcs |
Vertical wind turbine separate parts:
d generator:
2.vertical wind blades:
Note:
1.Concern Tower:
We can supply two kinds of tower for option, the advantage and disadvantage as follow:
(1).Guy cable tower: Cheapest tower. Cheaper delivery cost, light weight. But need more space and more concrete.
(2).Freestand tower: More beautiful. Need small area for foundation. No steel wire But a little expensive.
2. Concern controller/inverter:
(1).Optional by-pass function : The off grid system can have bypass function, that is to say grid switch function. When no wind, and battery no power, the inverter can switch to grid.Inverter has a build in switch to change from batteries to grid when the battery voltage is lower than rated voltage.
(2).Optional wind turbine low-voltage charge function, making full use of low wind power.
Our company:
Qingdao Jinfan Energy Science & Technology Co., LTD. is a professional wind turbine manufacturer. We have a strong research and development team. At present, our main products are
1.Vertical axis wind turbine:300W,500W,1KW,2KW,3KW,5KW
2.Vertical low RPM PMG:300W80RPM,500W80RPM,1KW50RPM,1KW100RPM,2KW50RPM,3KW50RPM,3KW100RPM,5KW50RPM,5KW100RPM,10KW50RPM,10KW100RPM,15KW125RPM
3.Horizontal axis wind turbine:300W,500W,1KW,2KW,3KW,5KW,10KW
4.Wind and solar hybrid (street lamp) system
