Technical Data
Ultraviolet sterilizer is constituted of a shell, UV sterilization lamps, negative ions, an activated carbon filter screen, an electrostatic adsorption plant, a fan and a control system
It can continuously sterilize dynamic ambient air by the principle of radiating circulating air with the UV sterilization lamp, as well as achieving continuous sterilization and refreshing air for indoors by combining the activate carbon filter screen, negative ions and the electrostatic adsorption plant.
Model No. |
Air Flow(m³/h) |
Applicable vol.(m³) |
Highly Effective Filtering |
Program Control |
Remote Control |
Input Watts (w) |
Installation Way |
SC-G60 |
≥600 |
≤60 |
√ |
√ |
√ |
≤180 |
Hanging-up type |
SCG80 |
≥900 |
≤80 |
√ |
√ |
√ |
≤200 |
|
SC-G100 |
≥1000 |
≤100 |
√ |
√ |
√ |
≤250 |
|
Disinfection effect Total count of bacteria(cfu/m³) |
≤200 |
||||||
Outer UV leakage(uw/cm2) |
≤0 |
||||||
Inner UV radiation intensity(uw/cm2) |
≥13800 |
||||||
Ozone concentration(mg/m³) |
≤0 |
||||||
Lamp life(h) |
≥6000 |
||||||
Negative oxygen ions released(No./M3) |
≥6×106 |
||||||
Supply Voltage |
220V/50Hz±10% |
||||||
Noise db(A) |
≤50 |
||||||
Principle of Sterilization
Functions
A. Disinfection effect: Steriiization rate of white staphylococcus 99.9%.
B. Filter, dust-removal and bacterium sterilization:
It uses the physical method to filter out the dust and microorganisms from the air, and coordinate with the UV to sterilize the air. It also could effectively prevent the dust from effecting the irradiance of UV tube, the sterilizer uses the removable and replaceable photocatalyst filter.
C. High intensity UV sterilization: The UV sterilizing tubes are scientifically composes the high intensity UV irradiation are with a irradiance of over 10000/cm2, driven by the fan, the room air will be flow through UV irradiation area in circulation and then be sterilized .
D. Fresh air containing oxygen anion: The oxygen anion is praised as Air Vitamins, which is necessary for the human life and health, a certain coots of the oxygen anion could improve the air quality in the room, and will be good for the human health.
E. Good reliability: The sterilizer use the physical sterilization. During the operation, it will not generate any harmful gas or substance, the high intensity UV light is enclosed in the airway of the sterilizer.the initial generation rate of ozone is less than or equal to 0.05g/kw/h, it will not be harmful to the human or equipments.
F. Easy operation: it is equipped with the functions such as manual timing sterilization, automatic monitoring of pollution source, program controlled.
