GFP12 Negative Pressure Filling Machine Vinegar Filling Machine

Name: GFP12 Negative Pressure Filling Machine Vinegar Filling Machine
Brand: JIAZHOU
SKU: 140471644

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Application:

Beverage

Packaging Type:

Bottles

Zhangjiagang Jiazhou Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Beverage

Packaging Type Bottles

Packaging Material Plastic, Other, Plastic, Wooden Case

Automatic Grade Semi-Automatic

Driven Type Electric

Voltage 380V50HZ

Power 0.75kw

Place of Origin Jiangsu, China

Brand Name JIAZHOU

Model Number GFP-12

Dimension(L*W*H) 1000*800*2000mm

Weight 500kg

Certification CE,ISO9001,BV,TUV

After-sales Service Provided Engineers available to service machinery overseas

GFP12 Negative Pressure Filling Machine Vinegar Filling Machine

1. Filling Type: Negative pressure filling.

2. Made of SUS316/304 as required, combined with bottle washing and capping machine

3. Advantages: no bottle broken, no leakage with overload protection and LCD equipment; and convenient maintenance.

Vinegar Filling Machine's Main Technical Parameter

Model		GFP-12	GFP-24	GFP-32
Production capacity(b/h)		1500-2500	3000-6000	5000-8000
Applicable bottle type(mm)	Glass bottle Polyester bottle	Inner diameter at inlet 15-18(mm)
		Outer diameter of bottle body 60-80(mm)
		Bottle height 200-320(mm)
	Pop-top can	Out diameter 53-65(mm)
		Height 90-133(mm)
Power(kw)		0.75	1.1	1.5
Overall dimensions(mm)		10008002000	133012602200	145017002500
Weight(kg)		500	800	1000
