Home > Packaging & Printing > Packing Machinery > Labeling Machine > PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine

PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine

Zhangjiagang Jiazhou Machinery Co., Ltd.
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine thumbnail-1
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine thumbnail-2
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine thumbnail-3
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine thumbnail-4
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine thumbnail-5
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine thumbnail-6
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine photo-1
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine photo-2
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine photo-3
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine photo-4
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine photo-5
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine photo-6
US$ 10,800 - 12,200 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Beverage, Chemical
Packaging Type:
Bottles
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai port for sleeve label machine
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Beverage, Chemical
Packaging Type Bottles
Packaging Material Wood
Automatic Grade Automatic
Driven Type Electric
Voltage 220V/380V
Power 4.8kw
Place of Origin Jiangsu, China
Brand Name JIAZHOU
Model Number SLM-150
Dimension(L*W*H) 300*900*1400mm
Weight 500KGS
Certification ISO9001CE
After-sales Service Provided Engineers available to service machinery overseas
Plastic Bottle Shrink Sleeve Labeling Machine
P/roduct informationZhangjiagang Jiazhou Machinery Co., Ltd.

Product descriptionPM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine

Plastic Bottle Shrink Sleeve Labeling Machine

1.The  hot sale bottle neck automatic heat shrink sleeve label machine is unwound evenly from the reel via feed roller and conveyed to the cutting unit via the sleeve supply unit.

 2. The  hot sale bottle neck automatic heat shrink sleeve label machine sleeve is opened by pulling it over a mandrel, a servomotor-controlled cutter cuts the sleeves exactly to the set length. After that, the under-brush pulls the sleeves over the container.

3. Depending on the container shape and the sleeve size, an optional positioning anna brush moves the sleeve to the desired position. As a result, each sleeve is in perfect position and cannot slip.

4.Optional hot-air nozzles shrink and pre-position the sleeves.After that, the sleeves are shaped perfectly around the container contour in a steam or hot-air tunnel.

Product displayPM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting MachinePM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting MachinePM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine
Product ParametersPM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine

Technical Parameters

Production capacity   150b/min
 Labeling accuracy   ± 1mm
 Label max width  190mm
 Bottle diameter 30-Φ100mm
 Label inner diameter 76.2mm
 Label outer diameter 330mm
 Outline size 2000×700×1400mm
 Air source  3-5kg   30L/min
 Using power     220V 50Hz 1200W
C/ompany informationZhangjiagang Jiazhou Machinery Co., Ltd.
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine
O/ur advantageZhangjiagang Jiazhou Machinery Co., Ltd.
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine
O/ur certificateZhangjiagang Jiazhou Machinery Co., Ltd.
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine
N/etwork MarketingZhangjiagang Jiazhou Machinery Co., Ltd.
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine
P/ackaging & shippingZhangjiagang Jiazhou Machinery Co., Ltd.
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine
C/ontact usZhangjiagang Jiazhou Machinery Co., Ltd.
PM-150 Factory Direct Sale Heat Shrink Sleeve Label Cutting Machine

Send Inquiry to This Supplier

Message
0/5000
Want the best price? Post an RFQ now!
Zhangjiagang Jiazhou Machinery Co., Ltd.
Business Type
Manufacturer
Year Established
1991
Factory Size
3,000-5,000 square meters
Annual Export Value
Below US$1 Million
Contact Supplier Request Quote Chat Now
