High Quality 5 Gallon Pure Water Barrel Filling Machine

Zhangjiagang Jiazhou Machinery Co., Ltd.
High Quality 5 Gallon Pure Water Barrel Filling Machine thumbnail-1
High Quality 5 Gallon Pure Water Barrel Filling Machine thumbnail-2
High Quality 5 Gallon Pure Water Barrel Filling Machine thumbnail-3
High Quality 5 Gallon Pure Water Barrel Filling Machine photo-1
High Quality 5 Gallon Pure Water Barrel Filling Machine photo-2
High Quality 5 Gallon Pure Water Barrel Filling Machine photo-3
US$ 2,000 - 10,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Condition:
New
Application:
Other, WATER, Drinking Water
Packaging Type:
Bottles
Contact Supplier Request Quote Chat Now
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Application Other, WATER, Drinking Water
Packaging Type Bottles
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Electric
Voltage 220V
Power 2.2KW
Place of Origin Jiangsu, China
Brand Name JIAAZHOU
Model Number QGF
Dimension(L*W*H) 3500*650*15550mm
Weight 2T
Certification CE ISO
After-sales Service Provided Engineers available to service machinery overseas

P/roduct informationZhangjiagang Jiazhou Machinery Co., Ltd.

Product descriptionHigh quality 5 gallon Pure Water Barrel Filling Machine

General Description

The machine is used for 3 gallon & 5 gallon water filling, which is composed of washer, filling and capper.

  1. 304 stainless steel insert type filling nozzle, two time high precision filling, filling volume adjustable.
  2. Water pump: 304 stainless steel pump. three washing pumps and one filling pumps.
  3.  Mitsubishi PLC controlling system, all full-automatic working, Schneider & Omron brand other electric parts
  4. With AIRTAC brand air cylinder, F.R.L. Combination and Electromagnetism valve for air cylinder.
  5. Machine frame and body: all 304 Stainless Steel, combine with clear fiber glass windows Automatic 5 gallon bottle washing machine
Product displayHigh quality 5 gallon Pure Water Barrel Filling Machine

High quality 5 gallon Pure Water Barrel Filling Machine



High quality 5 gallon Pure Water Barrel Filling Machine

Product ParametersHigh quality 5 gallon Pure Water Barrel Filling Machine

Main technical data

Model

QGF-100

QGF-300

QGF-450

QGF-600

QGF-900

QGF-1200

QGF-2000

Number of filling heads

1

2

3

4

8

12

16

Filling capacity

18.9

18.9

18.9

18.9

18.9

18.9

18.9

Barrel size (mm)

φ270×490

φ270×490

φ270×490

φ270×490

φ270×490

φ270×490

φ270×490

Production capacity (b/n)

100-120

200-240

300-400

600

900

1200

2000

Gas pressure (Mpa)

0.4-0.6

0.4-0.6

0.6

0.6

0.6

0.6

0.6

Gas consumption (m3/min)

0.37

0.6

0.6

1.2

2.2

3

4.5

Motor power(kw)

1.75

3.22

4.8

8.5

8.5

8.5

8.5

Rated voltage (V)

380V/50Hz

380V/50Hz

380V/50Hz

380V/50Hz

380V/50Hz

380V/50Hz

380V/50Hz

Overall dimension (mm)

3790×650
×1550

3550×800
×1800
2800×1100
×1800

3550×1200
×1800
3800×1100
×1800

3650×1500
×1800
3800×1100
×1800

2200×1860
×2700
not include cleaning

2560×2350
×2750
not include cleaning

3100×2800
×2750
not include cleaning
