Specifications
Dual Stage Isolator1.High Isolation
2.Low Insertion Loss
3.High Return Loss
Polarization-Insensitive Single/Dual Stage Isolator High Power optical fiber Isolator for FTTH
Feature
1.High Isolation ·
2.Low Insertion Loss ·
3.High Return Loss·
4.Polarization Dependent Loss
5. Epoxy free on optical path
Application
1.Optical Fiber Amplifier·
2.CATV Fiberoptic Link·
3.Fiberoptic System Testing
4.Fiberoptic LAN Systems
5.Telecommunications
Dual Stage Isolator Parameter
Operating Wavelength (nm) |
1310 or 1550 |
1480 |
||
Type |
Single Stage |
Dual Stage |
Single Stage |
Dual Stage |
Grade |
Grade P |
|||
Typical Peak Isolation (dB) |
≥42 |
≥58 |
≥42 |
≥58 |
Isolation (dB) |
≥32 |
≥46 |
≥32 |
≥46 |
Typical Insertion Loss(dB) |
0.3 |
0.5 |
0.4 |
0.5 |
Insertion Loss(dB) |
≤0.5 |
≤0.7 |
≤0.6 |
≤0.8 |
Return Loss(dB) |
≥60/55 |
|||
PDL (dB) |
< 0.05 |
|||
PMD (ps) |
0.2(0.05 available upon request) |
|||
Bandwidth(nm) |
±15 |
|||
Operating Temperature (°C) |
-20 ~ + 70 |
|||
Storage Temperature (°C) |
-40 ~ +85 |
|||
Optical Type |
Corning SMF-28 |
|||
Optical Length (Min.) |
1 Meter Each End |
|||
Max. Operating Power (mW) |
500 |
|||
Package Size (mm) |
1. Φ5.5xL30(250um bare fiber) 2. Φ5.5xL38 (900um Loose tube)) |
|||
