1480/1550nm Micro-Optic FWDM Wavelength Division Multiplexer

Features

Applications

Low insertion loss, High isolation

High stability and excellent reliability

Epoxy-free optical path

Broad operating wavelength range

Fiber optic metro networks

Fiber optic sensor systems

CATV systems

Fiber optic test equipment

Parameter

FWDM-45/54

Pass Channel Wavelength Range (nm)

1530 ~ 1580 (or 1440 ~ 1490)

Reflect Channel Wavelength (nm)

1440 ~ 1490 (or 1530 ~ 1580)

Insertion Loss (dB)

Reflect Channel

< 0.4

Pass Channel

< 0.6

Insertion Loss Variation(dB)

< 0.3

Isolation

Reflect Channel

> 12

Pass Channel

>30

Insertion Loss Temperature Sensitivity (dB/°C )

<0.003

Polarization Dependent Loss (dB)

<0.1

Polarization Mode Dispersion (ps)

<0.1

Directivity (dB)

>60

Return Loss (dB)

>50

Maximum Power Handling (mW)

300

Operating Temperature (°C)

0 ~+70

Storage Temperature (°C)

-40 ~+85

Package Dimension (mm)

Φ5.5 x L35
