Cheap building materials cold room panel price,50mm-100mm puf panel cold room panel
Specification
1.Name:PU Sandwich Panel
2.Other Types:Rock wool/EPS/Fiber glass
3.Brand:WZH polyurethane sandwich panel
4.Surface:Color Steel sheet
5.Light weight,thermal-insulation,waterproof,fireproof
Product Description
Polyurethane sandwich panel is fit for the projects which have strictly requirements of keeping warm.Polyurethane core material is considered to the best material in keeping warm
and thermal insulation.
The Polyurethane block material become steady after it froth,then combining with metal plates.
The characteristics of this technique are:the polyurethane froth,after this chemical reaction is stable
, we cut the polyurethane into pieces which with different thickness.The polyurethane sheet
material has stable physical performance, it can combine with pre-painted hot galvanized steel sheets or stainless steel sheet, the surface is smooth and the whole
performance is excellent.
Models of PU sandwich panel
WZH-PU-2015-960
WZH-PU-2015-1000/1150
Thickness:50mm-150mm
Rib height:8mm for wall-40mm for roof
Wave span:30mm for wall-320mm for roof
Wave no.:20 for wall-3 for roof
Effevctive Width:950mm for wall-960mm for roof
Length-Max 11800mm
Usage of PU sandwich panel
(1)-Roof
75mm-200mm PU sandwich roof panel
(2)-Wall
50mm-200mm PU sandwich wall panel
(3)-Cold room
Density |
38-46kg/m³ |
|
Thickness |
40mm-200mm |
|
Rib height |
8mm for wall |
40mm for roof |
Wave span |
30mm for wall |
320mm for roof |
Wave no. |
20 for wall |
3 for roof |
Effective Width |
960mm for wall |
960mm for roof |
Length |
Max 11800mm |
|
5 Usage of PU Sandwich panel | ||
(1) |
Roof |
|
(2) |
Wall |
|
(3) |
Cold storage |
|
PU sandwich wall panel
Technical Parameters
Steel Thickness |
0.2mm~1.2 mm |
Panel thickness |
50/75/100/125/150 mm |
Effective width |
(1) 960mm---for roof (2) 950/1150mm---for wall |
Length |
1200mm(5.8 m. MAX. for 20'GP and 11.8m.MAX.for 40'HQ or according to the buys’ request) |
Materials |
Inner is polyurethane,Plate surface is color steel sheet |
Structure |
three layers: (1)upper layer is steel sheet, (2)the inner layer is polyurethane , (3)the bottom layer is also steel sheet. |
EPS density |
40-60kg/m³,etc |
color |
red,tephrosious,blue,white.or according to RAL color |
parts |
Steel line for easy connect one by one Film covering in order to protect the steel of panels |
lifetime |
15~20 years |
Character |
Light in weight,heat insulation,waterproof,environmental-saving |
Application |
Cold storages, warehouse exhibition halls,gymnasiums,etc |
Packing |
PU Sandwich panel Packed by shipping Container or according to your demands |
Applications
Cold storage,Hotels,hospitals, blood banks,poultry slaughter and processing,aquaculture and processing, mushroom cultivation, agricultural product processing,dairy production, pharmaceutical processing and logistics, beverage production and processing, beer production and cooling, large-scale logistics storage, chemical product cooling, leather manufacturing,injection molding,machine cooling, steel cooling, communication equipment,ship manufacturing and more.
Advantages
1.Heat and sound insulation
The outer steel sheets can maintain the lastingness of the color of the building,and reduce the solar radiation and keep the appropriate indoor temperature.The high quality heat insulation materials are made with the adoption of polyurethane PU and (PIR) polyisocyanurate resin acid hydrogen containing no Chloro-fluoro-carbons (CFC).
Polyurethane Sandwich Panels thermal stability is quite good, when the temperature is lower than 120°C,
the volume and the intensity have no obvious change,its Thermal conductivity is small,when the
density is 0.03kg/m3, the heat conductivity is only 63J(m.h.k)(15cal/m.h.k).
2.A degree inflaming retarding
This system can effectively prevent the fire and prevent the fire from spreading during the cross construction and during the use of the boards. A class fire-resistance( 650.C)fire-resistance period(120min)
3.Environment protection
By learning after the successful experience in environment protection constructions from companies home and abroad and through our scientific analysis,we objectively bear the idea of “low carbon designing,environmental building materials and energy-saving technology” in mind.
4.Super-low heat conductivity
The lowest heat conducting coefficient of the heat insulation boards ensures that, under the condition that the thinnest heat insulation materials are used; the system can meet the energy-saving requirement and offer the strongest basic guarantee to meet the requirement of high standard heat insulation
5.SWE polyurethane roof panel are tightly connected blind nailing
6.Easily and quick installation
7.Long service life up to 20 years,very low cost in wastage and maintenance.
Our services:
We can supplier a service for the follow products Steel Structure,Prefabricated House,Galvanized Steel Coil,Galvalume Steel Coil,PPGI/PPGL,Galvanized Steel Sheet , Galvalume Steel Sheet,Cold Storage Panel,Prepainted Corrugated Steel Sheet | Floor Decking | EPS Sandwich Panel,Rock Wool Sandwich Panel | PU Sandwich Panel | Cleanroom Panel | FPR Panel the best service :
1.Sample free.the freight cost will be paid by customers.
2.You are very welcome to visit our factory before the order,or during the prodction or after the production before loading.
3.We are very professional in all kinds of different payment terms,FOB,CIF,CFR,CIP by sea container or by train.
4.For the steel frame you are very welcome to offer your own design,or you give us your ideas,we can supplies our design,the production,the loading all for you.
