Specifications
the top wire straightening and cutting machine1.High speed and high quality
2.Certain length
3.Adjustable length
4.CE
the top wire straightening and cutting machine
the top wire straightening and cutting machine
the top wire straightening and cutting machine
Model |
SC3-6 |
Dia.mm |
3-6 |
Cut Length mm |
30-6000 |
Cut Error mm |
±1 |
Speed m/min |
35 |
Straight Motor kw |
2.2 |
Cutting Motor kw |
0.75 |
Overall Size M |
1.3*0.55*1.1 |
Weight KG |
200 |
the top wire straightening and cutting machine
Other models
Model |
SC1.5-3.5 |
SC2-5 |
SC4-8 |
SC4-12 |
SCHA5-12 |
SCHB5-12 |
Dia.mm |
1.5-3.5 |
2-5 |
4-8 |
4-12 |
5-12 |
5-12 |
Cut Length mm |
30-2000 |
30-6000 |
200-6000 |
200-6000 |
700-12000 |
700-9000 |
Cut Error mm |
±1 |
±1 |
±1 |
±1 |
±10 |
±10 |
Speed m/min |
25 |
30 |
35 |
30 |
45 |
45 |
Straight Motor kw |
1.5 |
1.5 |
4 |
7.5 |
11 |
11 |
Cutting Motor kw |
0.75 |
0.75 |
3 |
4 |
4 |
4 |
Overall Size M |
1.7*0.4*0.8 |
1.2*0.4*0.9 |
7.3*0.6*1.2 |
8*0.8*1.3 |
2.1*0.7*1.3 |
1.9*0.6*1.4 |
Weight KG |
130 |
150 |
650 |
1000 |
1200 |
900 |
the top wire straightening and cutting machine
Hebei Dapu Import & Export Trade Co.,Ltd is engaged in designing, manufacturing and exporting metal & wire mesh processing machinery, different kinds mesh weaving and wire mesh welding machine which located in Shijiazhuang Hebei China.It has own factory-Hebei Jiake Welding Equipment Co.,Ltd located in industrial zone ,Anping, Hebei ,China.It is the leading manufacturer of mesh machine in China and we always offer advanced wire mesh technology.
