PLC Control Steel Mesh Welding Machine for Construction Mesh Made in China

PLC Control Steel Mesh Welding Machine for Construction Mesh Made in China photo-1
PLC Control Steel Mesh Welding Machine for Construction Mesh Made in China photo-2
PLC Control Steel Mesh Welding Machine for Construction Mesh Made in China photo-3
PLC Control Steel Mesh Welding Machine for Construction Mesh Made in China photo-4
PLC Control Steel Mesh Welding Machine for Construction Mesh Made in China photo-5
PLC Control Steel Mesh Welding Machine for Construction Mesh Made in China photo-6
US$ 40,000 - 60,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
JIAKE
Model Number:
JK-FM-2500S+
Payment & Shipping
Payment Methods:
Port of Shipment:
xingang
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Hebei, China
Brand Name JIAKE
Model Number JK-FM-2500S+
Condition New
After-sales Service Provided Engineers available to service machinery overseas

PLC Control Steel Mesh Welding Machine  for Construction Mesh

Wire diameter:4-8mm

mesh width:2.5m

mesh length:6m or as required

wire pitch:100-300mm or as required

The machine could be customized, please tell us your needs.

PLC Control Steel Mesh Welding Machine for Construction Mesh Made in ChinaPLC Control Steel Mesh Welding Machine for Construction Mesh Made in China



Technical Parameter

PLC control steel mesh welding machine JK-FM-2500S+ for construction mesh parameter:



wire diameter 4-8mm
Pitch wire 100-200mm
mesh length 6m or as requried
mesh width 2.5m or as required
Rated electrical 150KVA*6
number of line wire 24pcs
welding speed 45-60cross wires/minute
Product Description

PLC control steel mesh welding machine JK-FM-2500S+ for construction mesh description:

the welding wire mesh machine adopt synchronous control technology. welding time and separate welding are controlled based on windowa operation system. mesh drawing device is controlled by Panasonic servo-motor, which improves the precision of mesh opening size. the along pitch and transversal pitch are adjustable and easy to adjust.
PLC Control Steel Mesh Welding Machine for Construction Mesh Made in China
Finished Products

4-8mm CNC weld wire mesh machine JK-FM-2500S+ for construction mesh  end products

some sizes as listed:

Wire diameter(mm)

Pitch wire(mm)

Dimension of the mesh(mm)

Overlaps(mm)

Weight

Along

Transversal

along

transversal

length

width

along

transversal

1m2(kg)

1ks(kg)

6

5

100

300

6000

2400

150

50

2.73

39.36

5

5

100

100

6000

2400

50

50

2.73

39.36

6

6

100

100

6000

2400

60

50

4.44

63.94

8

8

100

100

6000

2400

50

50

7.9

113.76



PLC Control Steel Mesh Welding Machine for Construction Mesh Made in ChinaPLC Control Steel Mesh Welding Machine for Construction Mesh Made in China
Our Services

PLC Control Steel Mesh Welding Machine for Construction Mesh Made in China



Related Products

1.Wire Mesh Welding Machines JK-RM-2500B for reinforcing mesh or steel bar mesh

  • wire diameter 5-12mm
  • mesh width 2.5m
  • mesh length max 12m
  • aperture 100-300mm
  • welding electrode 24pcs
  • welding transformer 150KVA*12
  • welding speed: 30-65 cross wires/min
PLC Control Steel Mesh Welding Machine for Construction Mesh Made in China

2. Wire Mesh Welding Machines JK-FM-2500S for fence mesh or construction mesh



  • wire diameter 3-6mm
  • mesh width 2.5m
  • mesh length max12m
  • aperture 50-200mm
  • welding electrode 48pcs
  • welding transformer 150KVA*12
  • welding speed  45-75 cross wires/min
  • mesh drawing device, powered by Servo motor
  • line wire: pre-straightened and precut or coil wire
  • cross wire:pre-straightened and precut
  • end products: roll mesh or panel mesh
PLC Control Steel Mesh Welding Machine for Construction Mesh Made in China



3. Full Automatic Wire Mesh Welding Machine JK-AC-1200S for construction mesh or poultry cage mesh

  • wire diameter 2-3.5mm
  • mesh width 1.2m
  • mesh length as required
  • aperture 50-200mm as required
  • welding electrode :16pcs or 25pcs as required
  • welding speed: 80-90corss wires/min
  • mesh drawing device, powered by Servo motor
  • line wire and cross wire: both from coil wire
  • end products: panel mesh or roll mesh
PLC Control Steel Mesh Welding Machine for Construction Mesh Made in China



4. electric welded mesh machines for construction mesh

  • Wire diameter 0.8-2.0mm
  • mesh width 1.2-1.8m
  • mesh length as required
  • aperture 1/2"-4" as required
  • welding speed:80-120 cross wire/min
  • line wire and cross wire: both from coil wire
  • end products: roll mesh
PLC Control Steel Mesh Welding Machine for Construction Mesh Made in China



All our machines could be customized, please contact us for much more details
