Wire Mesh Welding Machinery
|
|
Wire Mesh Welding Machinery Main Parameter
| Model | JK-FM-2500S+ | JK-FM-2000S+ | JK-FM-1000S+ |
| Wire diameter | 4-8mm | 4-8mm | 4-8mm |
| Cross wire length (mesh width) | 2.5m | 2.0m | 1.0m |
| Line wire length (mesh length) | Max 6m | Max 6m | Max6m |
| Cross wire spacing | 100-300mm | 100-300mm | 100-300mm |
| Line wire spacing | 50-300mm | 50-300mm | 50-300mm |
| Welding spot | 24pcs | 20pcs | 6pcs |
| Welding transformer | 150KVA*12 | 150KA*10 | 150KVA*3 |
| Power | 3phase 50HZ 380V or 415V or 220v or as required | 3phase 50HZ 380V or 415V or 220v or as required | 3phase 50HZ 380V or 415V or 220v or as required |
Wire Mesh Welding Machinry Main Features:
- End products variety: the wire diameter could be from 4mm to 8mm, and mesh width could be 1.0m, 1.2m, 1.5m, 1.8m, 2.0m, 2.2m, 2.5m or as required, and wire space could be adjusted too. line wire space adjusted by moving the electrode, and cross wire spacing by parameter set on the touch screen, easy to get the size you want.
- Fast Welding speed: this kind of mesh weld machine could weld wire mesh in high speed 45-75 cross wires /min.
- Advanced performance: PLC control, all the welding parameter could be set on the touch screen in the client's native language, wasy to learn and operate.
- Best Quality Control: all the apparatus are adopts famous brand such as Panasonic PLC, Weinview touch screen, Panasonic servo motor and so on.
1. Cross Wire Input Device 2. Line Wire Input Device
3. Mesh Output Device 4. Electric Control Cabinet
1.Wire Mesh Welding Machines JK-RM-2500B for reinforcing mesh or steel bar mesh
|
|
2. Wire Mesh Welding Machines JK-FM-2500S for fence mesh or construction mesh
|
|
3. Full Automatic Wire Mesh Welding Machine JK-AC-1200S for construction mesh or poultry cage mesh
|
|
4. electric welded mesh machines for construction mesh
|
|
All our machines could be customized, please contact us for much more details
Our company has a sound service system, from customer requirements gathering, pre-sales technical consulting, installation and commissioning in sales, and after sales maintenance of equipment. All of service system only for your satisfaction.
A: Pre-sale service; plant layout design, technical consulting, feasibility studies, cost and ROI analysis;
B: sales services: installation and commissioning, operator training, electrician and mechanic training;
1.Equipment installation and commissioning: assist and guide customer coordinate the equipment layout according to the actual situation, make reasonable arrangements for the overall planing of the installation location. Assigned technician to provide equipment installation, operation, ancillary facilities, production, repair, maintenance services and answer the relevant questions.
2.Training operation and maintenance personnel: our company will provide training of the operation and maintenance personnel according to customer’s requirement.
C: after-sale service; supply spare parts and provide after-sale services
1.supply of spare parts: keep records for each customer, provide long-term supply of spare parts, and send it to customers hand with the fastest speed according to customers’ requirement.
2.Unexpected emergency repair service: once the equipment have malfunction, and the user unable to rule out, we will arrange technician to the user factory in the soonest time, solve the trouble and resume production in time.
Tell us your need, we will surprise you with best price, best quality and best service!
