2015 Automatic Welded Wire Mesh Machine Price
Type | DP-DNW-1 | DP-DNW-2 | DP-DNW-3 |
Mesh width | 914.4mm;1000mm | 1219.2mm;1524mm | 1219.2mm;1524mm; 1828mm;2133mm |
Aperture /pitch | 6.35mm-12.7mm | 12.7mm-101.6mm | 25.4mm-101.6mm |
Wire diametre | 0.4mm-0.65mm | 0.65mm-1.8mm | 1.0mm-2.2mm |
Motor | 2.2KW | 2..2KW | 2.2KW;4.0KW |
Welding speed | <=75rows/min | <=120rows/min | <=80rows/min |
Measurement of machine | 2.3M*1.3M*1.4M | 2.5M*1.3M*1.4M 2.9M*1.3M*1.4M | 2.5M*1.3M*1.4M 2.9M*1.3M*1.4M |
Weight | 1.5T | 2.0T;2.5T | 2.0T;2.5T;3.0T;3.5T |
Welded transformer capacity | 50kw*3 | 60kw*4;60kw*5 | 60kw*4;60kw*5;60kw* 6;60kw*7 |
1.Both longitude wire and cross wire are feeding from wire coils automatically.
2.The raw material is appliable for low-carbon steel wire,stainlesswire or galvanized steel wire.
3.The mesh size is precise and the machine can be set the width and length according to customer’s requirement.
4.It is made up of main welding machine, electrical control cabinet, repairing table, repairing machine, bracket for longitude wires, wire rolling machine and plastic rollers.
Main machine
Mesh rolling mould
Mesh rolling system
Finished mesh
Welcome to our factory!!!
