Specifications
expanded mesh machinefast working speed.
easy for operations,
low power consumption
Expanded Metal Mesh Machine
Expanded metal mesh machine are use for producing all kinds of expand mesh in construction, hardware, window and door, and machine protection. The metal material can be steel plate, aluminum plate, titanium plate, copper plate etc.
Expanded Metal Mesh Machine Main parameters:
Item | Model | |||||||
JK-A20 | JK-B10 | JK-150A | JK-300 | JK-150B | JK-2.5 | JK-4.0 | JK-8.0 | |
Max thickness | 1.0mm | 1.0mm | 1.0mm | 1.0mm | 1.25mm | 2.5mm | 4.0mm | 8.0mm |
Max width | 500mm | 500mm | 1000mm | 1000mm | 1250mm | 2000mm | 2000mm | 2000mm |
Stroke per minute | 180/min | 200-400/min | 150/min | 300/min | 150/min | 70/min | 60/min | 45/min |
Distance of feed | 0-1.2mm | 0-1.6mm | 0-1.2mm | 0-4mm | 0-2mm | 0-4mm | 0-4mm | 0-7mm |
Max LWD of mesh | 20mm | 10mm | 25mm | 25mm | 30mm | 100mm | 150mm | 160mm |
Motor power | 2.2kw | 2.2kw | 3.0kw | 4.5kw | 4kw | 11kw | 15ke | 30ke |
Weight | 950kg | 950kg | 2000kg | 2050kg | 3000kg | 11000kg | 12000kg | 21000kg |
Overall dimension(mm) | 1090*710*1450 | 1090*710*1450 | 1800*1320*1550 | 1470*850*1630 | 1940*1600*2010 | 2400*3500*2300 | 3600*2500*3000 | 3000*3200*4110 |
If you have any questions or need any help, please contact us when you feel free.
Contact: Daisy Lee
Hebei Jiake Welding Equipment Co.,Ltd
Mobile: :+86-318-15324391556
Fax:+86-0318-7565522
Skype:qq1815361000
