Full Automatic Cattle Field Fence Weaving Machines from JIAKE Factory Made in China
Description of Grassland Fence Machine
The grassland fence machine is used to weave wrap-around fence. It can weave the diameter wire and weft wire together automatically. It takes us many years to research and develop the machine, which has independent intellectual property rights. It adopts sophisticated computer control and advanced manufacturing technique.
Product of grassland fence machine
Loading pieces of the machine
Raw Material
It mainly consists of galvanized wire.
Technical parameter of the machine
Modal |
CY-A |
CY-B |
CY-C |
CY-D |
Mesh width |
1427mm |
1880mm |
2000mm |
2400mm |
Twine wire diameter |
1.9mm-2.5mm |
1.9mm-2.5mm |
1.9mm-2.5mm |
1.9mm-2.5mm |
Side wire diameter |
2.0mm-3.5mm |
2.0mm-3.5mm |
2.0mm-3.5mm |
2.0mm-3.5mm |
Voltage |
3-phase,380V,50Hz or according to client’s voltage |
|||
Motor |
5.5kw |
7.5kw |
7.5kw |
11kw |
Max. work efficiency |
≤45rows/min |
≤45rows/min |
≤45rows/min |
≤45rows/min |
Max. line wire number |
11 |
13 |
18 |
23 |
Min. weft opening |
75mm |
75mm |
75mm |
75mm |
Size of the machine |
2.8M*3.2M*2.4M |
3.3M*3.2M*2.4M |
3.4M*3.2M*2.4M |
3.9M*3.4M*2.4M |
Weight of the machine |
3.0T |
3.5T |
4.0T |
4.5T |
The warp opening |
100mm,200mm,300mm or 150mm,300mm |
100mm,200mm,300mm or 150mm,300mm |
100mm, 200mm, 300mm or 150mm, 300mm |
100mm,200mm,300mm or 150mm,300mm |
The line wire opening |
|
|
|
6*75mm+11*100mm+3*150mm+2*200mm |
Features of Grassland Fence Machine
1. It is novel and automatic.
2. It is safe and simple to operate.
3 It is reliable and has long life.
4. It is inexpensive.
5. All the parts works coordinately and smoothly.
6. The finished products is neat and beautiful.
7. It can produced diverse specification of grassland fence.
Functions of Grassland Fence Machine
1.It is widely used in grasslands, pastures,mountains and protects the natural environment.
2.It is also applied to poultry, etc.
Hebe Jiake Welding Equipment Co.,Ltd mainly produce reinforcing mesh welding machine, fence mesh welding machine, construction mesh welding machine, chicken cage mesh welding machine, 3D panel production line, filter mesh welding machine, steel bar cage making machine, chain link fence machine, gabion mesh machine, nail making machine, barbed wire machine, welded wire mesh machine, razer barbed wire machine, steel grating mesh welding machine, fence mesh weaving machine, stainless steel wire mesh weaving machine and so on.
| CS-A TYPE BARBED WIRE MACHINE | |
|
| RAZOR BARBED WIRE MACHINES | |
|
| FENCE MESH WELDING MACHINE | |
|
| CHAIN LINK FENCE MACHINE | |
|
Our company has a sound service system, from customer requirements gathering, pre-sales technical consulting, installation and commissioning in sales, and after sales maintenance of equipment. All of service system only for your satisfaction.
A: Pre-sale service; plant layout design, technical consulting, feasibility studies, cost and ROI analysis;
B: sales services: installation and commissioning, operator training, electrician and mechanic training;
1.Equipment installation and commissioning: assist and guide customer coordinate the equipment layout according to the actual situation, make reasonable arrangements for the overall planing of the installation location. Assigned technician to provide equipment installation, operation, ancillary facilities, production, repair, maintenance services and answer the relevant questions.
2.Training operation and maintenance personnel: our company will provide training of the operation and maintenance personnel according to customer’s requirement.
C: after-sale service; supply spare parts and provide after-sale services
1.supply of spare parts: keep records for each customer, provide long-term supply of spare parts, and send it to customers hand with the fastest speed according to customers’ requirement.
2.Unexpected emergency repair service: once the equipment have malfunction, and the user unable to rule out, we will arrange technician to the user factory in the soonest time, solve the trouble and resume production in time.
