chicken hexagonal wire mesh net making machines
- 20 Set / Sets per Month
- Xingang port China
- T/T L/C D/P D/A Credit Card PayPal
- 4 axis CNC Milling Machine To Router 2d 3d Woodworking Craft
- Jotun JT-SDJ Industrial Automatic Metal Sheet Surface Polishing Machine
- Large Metal Sheet Metal Workpiece Processing Deburring Chamfering Plane Belt Polishing Machine
- Heavy Duty Automatic Wide Belt Metal Sand Deburring Machine
- Metal Plate Deburring and Rust Removal Machine Steel Plate Sand Belt Drawing and Polishing Equipment Flat Polishing Machine
- Metal Flat Sheet Laser Cutting Parts Deburring Grinding Polishing Machine Manufacturer
Product Details
Place of Origin: | Hebei, China | Brand Name: | JIAKE | Model Number: | NW20-22 |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
chicken hexagonal wire mesh net making machines
1. Guarantee period: 12 months (but no longer than 18 months since departure from Xingang Port)
2. Our engineers are available to install and maintain machine overseas.
3. Customized machine.
4. OEM support.
5. Fast delivery.
6. Moderate price.
7. Door to Door service or 24-hour email service.
1. It has advanced design and compact conformation.
2. It has attractive appearance.
3. It is easy and safe to operate.
1. produce hexagonal screens made of galvanized or low-carbon steel wires.
2. adopt horizontal type to ensure smooth running and high productivity.
3. Auxiliary equipments include spool winding machine and spiral coil machine.
Technical parameter
Type | Mesh width | Mesh opening | Wire diameter | Motor capacity | Number of Twists | Weight | |
| mm | mm | Inch | mm | KW |
| T |
NW12 |
1200-2300
| 12 | 3/8 | 0.38-0.5 |
2.2
|
3 or 5
|
2-2.5
|
NW15 | 15 | 1/2 | 0.4-0.7 | ||||
NW18 | 18 | 5/8 | 0.38-0.7 | ||||
NW20-22 | 20-22 | 3/4 | 0.38-0.8 | ||||
NW25-27 | 25-27 | 1 | 0.5-1 | ||||
NW30-32 | 30-32 | 1.2 | 0.5-1 | ||||
NW40-44 | 40-44 | 1.5 | 0.4-1.3 | ||||
NW50 | 50 | 2 | 0.5-1.5 | ||||
NW75 | 75 | 3 | 0.5-1.65 | ||||
NW100 | 100 | 4 | 0.5-1.8 | ||||
Note: the last three types are customized types. |
Main machine
Finished products
Application
Hexagonal wire net is used for chicken cages, construction, heat insulation, heat preservation, and fences.
