High speed automatic wire mesh fence welding machine
High speed automatic wire mesh fence welding machine adopts synchronous control skill. The welding time and separate welding are controlled by PLC based on touch screen system, which makes the operation more intelligentized. Mesh drawing system is controlled by servo-motor., which improves the precision of mesh opening size. Meanwhile the longitudinal and transversal spacing are adjustable. It simplifies the process that every tensile spring has to be changed when the welding wire diameter is different. Only need to change the pressure of welding point.
Welding Transformer:
This machine equips typical and efficient transformer, which has 8-gear, so it enlarges welding range. Professional electrode makes the wear low; it is also used in many sides.
Drawing Mesh System:
It is controlled by computer and servo motor, the distance of weft could adjust steplessly, the mesh size change is settled by the program, it could have different weft distances on one piece of mesh sheet. And it drawing mesh by cycle automatic, so make the machine can weld extra length mesh.
Control System:
It adopts PLC program controller, the operation is convenient with (touching screen) , and it is easy to learn and use.
Feed Cross Wire System:
This system adopts patent technology, sending wire one by one, it need not put wires by manual work.
Use of Mesh Sheet:
Welding highway fence panel, railway fence panels, wire mesh panels and construction mesh panels etc.
Main Advanced Technology & Parameter:
1. Panasonic (Japan) PLC program, Weinview (Taiwan) touch screen.
2. Multiple languages of program can be elected to design.
3. Schneider (France) low-voltage apparatus, Delta (Taiwan) variable-frequency drive.
4. Panasonic (Japan) servo motor for pulling mesh, big power, high precision.
5. Brake clutch motor connect the principal axis directly, high stability, big power. (Patent technology)
6. Casting water-cooling transformers and water-cooling welding electrodes, high efficiency.
Power |
3 Phase 380V 50Hz |
Measurement(L*W*H) |
8480mm x 3160mm x 1700mm |
Weight |
4.2 Ton |
Rated capacity |
125KVA*6sets |
Max. Welding width |
2500mm |
Wire diameter |
3.0-6.0mm |
Line wire space |
50mm-200mm (3mm≤dia.≤5mm) 100mm-200mm(5mm<dia.<6mm) |
Cross wire space |
50mm-200mm |
Line wire from |
Pre-cut wire |
Cross wire from |
Pre-cut wire |
Frequency conversion motor |
5.5KW |
Finished mesh style |
Mesh panel |
Number of electrode(welding point) |
48 sets |
Welding speed |
50-75 times/min |
The main machine and auxilary equipment with plastic ,then put the spare parts into wooden box ,use the steel wire to fasten the easy damages parts to keep its safety and not be hit during the ship,the full line need 1*20'' container to hold , the auxilary equipments we also use wooden box to pack them.
A: Pre-sale service; plant layout design, technical consulting, feasibility studies, cost and ROI analysis;
B: sales services: installation and commissioning, operator training, electrician and mechanic training;
1.Equipment installation and commissioning: assist and guide customer coordinate the equipment layout according to the actual situation, make reasonable arrangements for the overall planing of the installation location. Assigned technician to provide equipment installation, operation, ancillary facilities, production, repair, maintenance services and answer the relevant questions.
2.Training operation and maintenance personnel: our company will provide training of the operation and maintenance personnel according to customer’s requirement.
C: after-sale service; supply spare parts and provide after-sale services
1.supply of spare parts: keep records for each customer, provide long-term supply of spare parts, and send it to customers hand with the fastest speed according to customers’ requirement.
2.Unexpected emergency repair service: once the equipment have malfunction, and the user unable to rule out, we will arrange technician to the user factory in the soonest time, solve the trouble and resume production in time.
Hebei Jiake Welding Equipment Co., Ltd. founded in 2000, located at the junction of Beijing, Tianjin and Shijiazhuang, Anping County, which is famous as “Hometown of wire mesh” in China, is a professional manufacturer for wire mesh machineries. The company has been developing smoothly and quickly and it has more than 100 employees. And the company has own wire mesh machineries and several pilot plants with strong technical force and advanced production and checkout equipments.
Our main products: 3D panel production line, steel bar mesh welding machine, CNC fence mesh welding equipment , 3D panel wire mesh machine (Bevel inserting combination joint machine), welding equipment of mine sieve mesh, chicken cage mesh welding machine, electric welded mesh machine and so on.
