High Quality Low Carbon Steel Wire Barbed Wire Making Machine factory
CS-A type Barbed Wire Machine
The materials of barbed wire machines used are general hot-dipped galvanized low carbon steel wire and plastic coated wire. The products of barbed wire machine
are widely used in national defense fence, railway fence , highway fence, agriculture mesh, animal
husbandry fence and other industries.
Barbed wire machine main parameters:
No. | Item | Units | Parameters |
1 | Motor power | KW | 3 |
2 | Main drive shaft speed | r/min | 402 |
3 | Strand wire diameter | mm | 2.2-3.0 |
4 | Barbed wire diameter | mm | 1.8-2.2 |
5 | Barb distance | Mm | 76(3”) 102(4”) 127(5”) |
6 | Twist number | Pcs | 3.5 |
7 | Theoretical output | Kg/h | 70 |
8 | Total weight | Kg | 1200 |
9 | Dimension of main part | mm | 1950*950*1300 |
10 | Dimension of take-twisting part | mm | 1760*550*760 |
Note: Special specification models of barbed wire machines can be customized according to
customer requirements.
CS-B type Single Strand Barbed Wire Machine
The materials of barbed wire machine used are general hot-dipped galvanized low carbon steel wire and low-strength steel wire. Main feature: saving materials.
Barbed wire machine main parameters:
No. | Item | Units | Parameters |
1 | Motor power | KW | 2.2 |
2 | Main drive shaft speed | r/min | 355 |
3 | Strand wire diameter | mm | 2.2-3.0 |
4 | Barbed wire diameter | mm | 1.8-2.2 |
5 | Barb distance | Mm | 102(4”) 127(5”) |
6 | Theoretical output | Kg/h | 40 |
7 | Total weight | Kg | 1000 |
8 | Dimension | mm | 3100*1000*1150 |
Note: Special specification models of barbed wire machine can be customized according to
customer requirements.
CS-C type Straight and Reverse Twisted Barbed Wire Machine
The materials of barbed wire machine used are general hot-dipped galvanized low carbon steel wire and low-strength steel wire, using straight and reverse twist way for winded the twist. The barbed
wire products has no rebound and winding phenomenon, so it is more beautiful compared with
ordinary barbed wire.
Barbed wire machine main parameters:
No. | Item | Units | Parameters |
1 | Motor power | KW | 2.2 |
2 | Main drive shaft speed | r/min | 355 |
3 | Strand wire diameter | mm | 1.6-2.8 |
4 | Barbed wire diameter | mm | 1.6-2.2 |
5 | Barb distance | Mm | 102(4”) 127(5”) |
6 | Twist number | Pcs | 7 |
7 | Theoretical output | Kg/h | 40 |
8 | Total weight | Kg | 1000 |
9 | Dimension | mm | 3000*1000*1150 |
Note: Special specification models of barbed wire machine can be customized according to
customer requirements.
1.Wire Mesh Welding Machines JK-RM-2500B for reinforcing mesh or steel bar mesh
| |
2. Wire Mesh Welding Machines JK-FM-2500S for fence mesh or construction mesh
| |
3. Full Automatic Wire Mesh Welding Machine JK-AC-1200S for construction mesh or poultry cage mesh
| |
4. electric welded mesh machines for construction mesh
| |
All our machines could be customized, please contact us for much more details
Our company has a sound service system, from customer requirements gathering, pre-sales technical consulting, installation and commissioning in sales, and after sales maintenance of equipment. All of service system only for your satisfaction.
A: Pre-sale service; plant layout design, technical consulting, feasibility studies, cost and ROI analysis;
B: sales services: installation and commissioning, operator training, electrician and mechanic training;
1.Equipment installation and commissioning: assist and guide customer coordinate the equipment layout according to the actual situation, make reasonable arrangements for the overall planing of the installation location. Assigned technician to provide equipment installation, operation, ancillary facilities, production, repair, maintenance services and answer the relevant questions.
2.Training operation and maintenance personnel: our company will provide training of the operation and maintenance personnel according to customer’s requirement.
C: after-sale service; supply spare parts and provide after-sale services
1.supply of spare parts: keep records for each customer, provide long-term supply of spare parts, and send it to customers hand with the fastest speed according to customers’ requirement.
2.Unexpected emergency repair service: once the equipment have malfunction, and the user unable to rule out, we will arrange technician to the user factory in the soonest time, solve the trouble and resume production in time.
Tell us your need, we will surprise you with best price, best quality and best service!
