Specifications
Line wire space25-200mmCross wire space25-200mm
Line wire diameter1.8-3.0mm
Cross wire diameter1.8-2.5m
|
poultry cage welding machines Model No. |
units |
Poultry Cage Welding Machine for bottom mesh |
1set |
Poultry Cage Welding Machine for top mesh |
1set |
B.Poultry Cage Welding Machine for bottom mesh
1.Main parameter:
|
JK-120B-1 |
Input power |
380V 50Hz |
Max. width |
1200mm |
Line wire space |
25-200mm |
Cross wire space |
25-200mm |
Line wire diameter |
1.8-3.0mm |
Cross wire diameter |
1.8-2.5mm |
Rated capacity |
60kva*2 |
Welding point No. |
16 |
Motor power |
2.2KW |
Feed line wire |
Coil wire |
Feed cross wire |
Coil wire |
Cutting mesh |
Automatic & Manual |
Welding speed |
55 times/min |
Weight |
2500kg |
Dimension(L*W*H) |
2500*1800*1400mm |
2.Main features:
This machine adopts electrical synchronous control technique, both welding time and separate-control welding is composed of digital and integrated electric circuit. This operation is accurate, it has
stable function, firm welded point, and without welded tracks.
Not only welding speed is fast, but also it is easy to learn and operate. Feeding material from coil
wire or from the fallen wire structure and drawing materials are automatic, so it is even and accurate,
the edge of mesh is regular, it is unnecessary to slice the ends. Drawing mesh adopts the device with
elastic tension and fixing mesh, it is easy to regulate mesh hole, and mesh size is rather accurate,
welding aperture could also adjust randomly within range.
C.Poultry Cage Welding Machine for top mesh
1specification
|
JK-120B-2 |
Input power |
380V 50Hz |
Max. width |
1000mm |
Line wire space |
25-200mm |
Cross wire space |
25-200mm |
Line wire diameter |
1.8-3.0mm |
Cross wire diameter |
1.8-2.5mm |
Rated capacity |
60kva*2 |
Welding point No. |
12 |
Motor power |
2.2KW |
Feed line wire |
Coil wire |
Feed cross wire |
Coil wire |
Cutting mesh |
Automatic |
Welding speed |
55 times/min |
Weight |
2500kg |
Dimension(L*W*H) |
7500*1800*1400mm |
Pneumatic
Automatic cutting mesh and automatic cutting edge.
The machine can be customized, please contact us for more info.
We can customize the fence mesh welding machines, reinforcing mesh welding machine, animal cage mesh welding machine, wire mesh welding machine, welded wire mesh machine, chain link fence machine, hexagonal wire netting machine, gabion mesh machine, stone mesh machine, expanded metal mesh machine, barbed wire machine, razor barbed wire machine and so on, please do not hesitate to contact us.
