Specifications
Wire diameter:1.8-3.0mmWelding aperture:25-200mm
Width:1200mm
Welding spot:16
chicken cages mesh welding machines Function Characteristics:
1. chicken cages mesh welding machine adopts electrical & electronic control technique,
both welding time and separate-control welding is composed of digital and integrated electric circuit.
2. The operation is accurate, it has stable function, firm welded point, and without welded tracks.
3. Not only welding speed is fast, it is easy to learn and operate.
4. The machine is equipped with precise equipment for weft cutting positioning, so the length of wefts is
identical and regular, it is unnecessary to slice the side.
5. Drawing mesh system adopts elastic tension and opening positioning mesh, it is easy to regulate mesh
hole, and mesh opening size is rather accurate, welding aperture could adjust randomly within range.
chicken cages mesh welding machines Use of the product:
1. Welding for breed aquatic/animal cage mesh (poultry cage mesh, coop, pigeon cage
mesh, bird cage mesh, chicken cage mesh, rabbit cage mesh, pet cage mesh and breed dog cage)
2. Building (reinforcing construction mesh, floor warming mesh, seed-bed mesh)
chicken cages mesh welding machines Main parameters:
| JK-120B-1 | JK-120B-2 |
Input power | 380V 50Hz | 380V 50Hz |
Max. width | 1200mm | 1200mm |
Line wire space | 25-200mm | 25-200mm |
Cross wire space | 25-200mm | 25-200mm |
Line wire diameter | 1.8-3.0mm | 1.8-3.0mm |
Cross wire diameter | 1.8-2.5mm | 1.8-3.0mm |
Rated capacity | 60kva*2 | 60kva*2 |
Welding point No. | 16 | 16 |
Motor power | 2.2KW | 2.2KW |
Feed line wire | Coil wire | Coil wire |
Feed cross wire | Coil wire | Coil wire & Pre-cut wire |
Cutting mesh | Automatic & Manual | Automatic & Manual |
Welding speed | 55 times/min | 55 times/min |
Weight | 2500kg | 2800kg |
Dimension(L*W*H) | 2500*1800*1400mm | 2500*1800*1500mm |
Accessorial Parts:Straightening&cutting wire machine; Repairing mesh machine; Electric control cabinet;
Wire plate(16 pcs); Electric scissors(2 pcs)
chicken cages welding machines After-sales service:
1.We offer installation and train the workers for the customers.
2.Guarantee time:one year since the machine was installed at buyer's factory but within 18 months
against B/L date.
3. We can help design the layout of the machine placed in the factory.
We can customize the fence mesh welding machines, reinforcing mesh welding machine, animal cage mesh welding machine, wire mesh welding machine, welded wire mesh machine, chain link fence machine, hexagonal wire netting machine, gabion mesh machine, stone mesh machine, expanded metal mesh machine, barbed wire machine, razor barbed wire machine and so on, please do not hesitate to contact us.
Contact: Daisy Lee
Hebei Jiake Welding Equipment Co.,Ltd
Mobile: :+86-318-15324391556
Fax:+86-0318-7565522
Skype:qq1815361000
Send Inquiry to This Supplier
