Specifications
welding for breeding aquatic mesh (chicken cage, poultry cage, coop cage, pigeon cage, rabbit cage and bird cage and so on)Breed Aquatics Mesh Welding Machine
Breed Aquatics Mesh Welding Machine Function Characteristics:
1.This machine adopts electrical synchronous control technique, both welding time and separate-control welding is composed of digital and integrated electric circuit.
2.This operation is accurate,it has stable function, firm welded point, and without welded tracks.
3.Not only welding speed is fast, but also it is easy to learn and operate.
4.Feeding material from coil wire or from the fallen wire structure and drawing materials are automatic, so it is even and accurate, the edge of mesh is regular, it is unnecessary to slice the ends. Drawing mesh adopts the device with elastic tension and fixing mesh, it is easy to regulate mesh hole, and mesh size is rather accurate, welding aperture could also adjust randomly within range.
Breed aquatics mesh: welding for breed aquatic mesh(poultry mesh, coop, pigeon mesh, rabbit mesh and so on.)
Breed Aquatics Mesh Welding Machine Main parameters:
| JK-120B-1 | JK-120B-2 |
Input power | 380V 50Hz | 380V 50Hz |
Max. width | 1200mm | 1200mm |
Line wire space | 25-200mm | 25-200mm |
Cross wire space | 25-200mm | 25-200mm |
Line wire diameter | 1.8-3.0mm | 1.8-3.0mm |
Cross wire diameter | 1.8-2.5mm | 1.8-3.0mm |
Rated capacity | 60kva*2 | 60kva*2 |
Welding point No. | 16 | 16 |
Motor power | 2.2KW | 2.2KW |
Feed line wire | Coil wire | Coil wire |
Feed cross wire | Coil wire | Coil wire & Pre-cut wire |
Cutting mesh | Automatic & Manual | Automatic & Manual |
Welding speed | 55 times/min | 55 times/min |
Weight | 2500kg | 2800kg |
Dimension(L*W*H) | 2500*1800*1400mm | 2500*1800*1500mm |
We can customize the machine, please tell us your needs.
