Galvanized Steel Sheet for Wall and Roof
US$ 2 - 8
MOQ: 25 Tons
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
STL
Material:
Galvanized Sheet
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Zinc Aluminum Roofing SheetUS$ 2 - 8MOQ: 25 Tons -
High Quality Zinc Roofing SheetUS$ 2 - 8MOQ: 25 Tons
-
Galvanized Corrugated Roof Sheets/tileUS$ 2 - 8MOQ: 25 Tons
-
Galvanized Corrugated Steel Tile for Wall and RoofUS$ 2 - 8MOQ: 25 Tons
-
Zinc Corrugated Steel Sheet for Wall Anf RoofUS$ 2 - 8MOQ: 25 Tons
Place of Origin
Shandong, China
Brand Name
STL
Material
Galvanized Sheet
Specifications
1)Easy installation(2)High strength
(3)Low in costs
(4)Durable
Detailed Product Description
Our products passed the ISO 9000/9001/9004/19011: 2000.
Our spacifictions are following:
1Thickness (mm):0.18-1.00
2Width (mm):750.00 / 760.00 / 820.00 / 840.00 / 880.00 / 900.00/920.00
3Length: according to your requirement
Specification:
| Product | zinc aluminium roofing sheets/ galvanized Corrugated Steel Sheets/corrugated plastic roofing sheets |
| Brand | STL zinc steel plate |
| Base material | Hot dipped galvanized steel |
| Thickness | 0.18-1.00mm |
| Width | 840mm(according to your need) |
| Quality | SGCC,SPGC,SPCD,SPCE |
| Zinc-coating | 40g/m2-120g/m2 |
| Technique | Cold rolled-hot dipped galvanizing |
| Painting | Top painting:16~25μm |
| Back painting: 6~10μm | |
| Tolerance | Thickness: +/-0.02mm |
| Width:+/-2mm |
| common types as below: | ||||||
| Type | spead width | valid width | height of wave | wave distance | wave numbers | application |
| YX28-205-820 | 1000mm | 820mm | 28mm | 205mm | 4 | roof |
| YX35-125-750 | 1000mm | 750mm | 35mm | 125mm | 6 | roof,wall |
| YX8-130-910 | 1000mm | 910mm | 8mm | 130mm | 7 | roof |
| YX35-280-840 | 1000mm | 840mm | 35mm | 280mm | 3 | roof,wall |
| YX25-210-840 | 1000mm | 840mm | 25mm | 210mm | 4 | roof,wall |
| YX51-250-750 | 1000mm | 750mm | 51mm | 250mm | 3 | roof,wall |
| YX16-65-850 | 1000mm | 850mm | 16mm | 65mm | 13 | roof,wall |
| YX30-160-800 | 1000mm | 800mm | 30mm | 160mm | 5 | roof,wall |
| YX15-225-900 | 1000mm | 900mm | 15mm | 225mm | 4 | roof |
| YX10-110-880 | 1000mm | 880mm | 10mm | 110mm | 8 | roof |
| YX12-108-864 | 1000mm | 864mm | 12mm | 108mm | 8 | wall |
| YX40-250-750 | 1000mm | 750mm | 40mm | 250mm | 3 | roof |
| YX35-210-840 | 1000mm | 840mm | 35mm | 210mm | 4 | roof |
| YX28-200-800 | 1000mm | 800mm | 28mm | 200mm | 4 | roof |
| YX40-261-787 | 1000mm | 787mm | 40mm | 261mm | 3 | roof |
| YX28-200-800 | 1200mm | 1000mm | 28mm | 200mm | 4 | roof |
| YX25-248-992 | 1200mm | 992mm | 25mm | 248mm | 4 | roof |
| LM-C10 | 1250mm | 1100mm | 10mm | 100mm | 11 | roof |
| LM-C21 | 1250mm | 1000mm | 21mm | 100mm | 10 | roof |
| LM-C44 | 1250mm | 1000mm | 44mm | 200mm | 5 | roof |
| LM-H57 | 1250mm | 750mm | 57mm | 187.5mm | 4 | roof |
| LM-H60 | 1250mm | 845mm | 60mm | 211.3mm | 4 | roof |
| LM-H75 | 1250mm | 750mm | 75mm | 187.5mm | 4 | roof |
Characteristics:
1.Highly strength,can resistance the wind below level 12 and has good aseismicity
2.Easily installed and serviced
3.Environmental protection. Our colour steel plate can be reused for several times
4. Be of light weight, less than 14kg for per square meter, can sufficiently reduce structure load, and reduce the cost of the structure
|
yx76-344-688 |
yx75-200-600 |
yx51-240-720 |
|
yx76-380-760 |
yx54-410-820 |
yx35-125-750
|
|
yx25-210-840 |
yx25-205-825(1025) |
yx20-215-860(1075) |
|
yx15-225-900 |
yx14-63.5-850 |
yx12-110-880 |
