ISO 9001 2000 Quality management system factory
binding wire
Amarre de alambre
BWG 8-22,0.71-4.1mm , Hot sale BWG18,20,21,22
Galvanized binding wire ,electro galvanized ,zinc coating 8-15g/m2
Black annealed binding wire
T/S:35-55kgf/mm2
Soft quanlity
Weight per coil/roll: 0.5kg,0.7kg, 1kg ,5kg, 8kg coil,10kg coil,25kg/coil,50-500kg coil
packing with plastic film inside woven bag or hessian cloth /jute bag ouitside
Use in construction,binding,baling,tie,lacing etc.
Galvanized iron wire | |
Specification | 0.3mm-7.5mm |
Zinc Rate | 30g-300g/m2 |
Tensile strength | 30kg-360kg/m2 |
Elongation Rate | 10%-25% |
Weight/Coil | 0.1kg-1000kg/coil |
Packing | plastic inside and hessian woven outside,plastic inside and nylon woven outside |
Scope of application:
armouring wires for cable;reinforcing wires for high pressure houses;wires for wearing, netting; wires for filters.
H.S number | product name | dia (mm) |
allow tolerance (mm) |
tensile strength (N/mm2) | elongation |
zinc coated (g/m2) | number |
| 72172000 | galvanized wire | 0.20-0.55 | ±0.01 | 300--400 | min 15% | min 20 | JQ--001 |
| 0.20-0.55 | ±0.01 | 300--400 | min 20 | JQ--002 | |||
| 0.56-1.60 | ±0.02 | 300--500 | min 25 | JQ--003 | |||
| 1.80-6.00 | ±0.02 (1.80--2.80) | 400--1400 | min12% (max600N/mm2)
| 50-350 | JQ--004 | ||
±0.03 (3.00--5.00) | max 5% (min 600N/mm2) | ||||||
electro galvanized wire |
0.30-1.30
| ±0.01 | 300--370 | min15% | 10--15 | JQ--005 | |
0.70-1.30
| ±0.01 | 300--490 | min15% | JQ--006 | |||
1.50-6.00
| ±0.02 | max550 | min15% | 10--50 | JQ--007 |
