Thermoplastic Road Marking road Paints is powder before fuse, need to be fuse before applying. it's features than cold type road marking paint is long life, strong sticking to asphalt or concret road surface. high reflective, easy transportation and stock.
Specifications of road paint:
| Color | White,yellow or OEM |
| Material | Resin, glass beads, rosin,quartz,pigment. |
| Percentage of micro glass beads | 28-35% |
| Type | Not spraying but extrusion type |
| Application | Stuitable to coating all kinds of road marking, letters and else road signs. |
| Application temperature | 180-190C |
| Application way | Road marking machine and pre heater |
| Suitable temperature | -40-60°c |
| Ddrying time | In 5 min's after application on normal temperature and thickness below 3.2mm |
| Packaging | 25kgs/double layer water proof bag. |
Features of road paint:
1. Has high adhesive and corrosion resistance qualities.
2. It is flexible.
3. Dries very fast.
4. It is not subject to discoloration in time.
5. It is a reflective paint.
6. Due to its pigment structure, it is easily visible at night time.
7. Application method include spary, screed/extruded, profiled.
Application of road paint:
It is stuitable to coating all kinds of road marking, letters and else road signs.
APPLICATION WAY:
1. Heating upto 180-190°c, thermoplastic will be molten.
2. Transfer thermoplastic into thermoplastic road marking machine
3. Keep the tank warm of road marking machine. so that it will not gels before application.
4. Mark the line according to requirement.
5. Approve car pass the new coating line only after it dtry, commonly in 10 min's.
Dosage:
| Weight of thermoplastic | Coating thickness | Coating area | Quantity glass beads |
| 1T | 1.5mm | 270m² | 100kgs |
ATTENTION:
1. Do not smoke during application.
2. Do not over heating the thermoplastic paint. or the color will appear not as required.
3. Cement road surface need coating oil to add its adhensive ability of thermoplastic paint.
Equipment need:
Thermoplastic paint pre heater
Thermoplastic road marking machine
We supply types of Thermoplastic Road Marking Machine:
| Item No. | OR-XMT-01 | OR-XMT-02 | OR-XMT-03 | OR-XMT-10 | OR-XMB-01 |
| Type | Push hot melt road marking equipment | The self-propelled hot melt marking machine | The self-propelled convex hot melt marking machine | AUTOMATIC driving type hot melt marking machine | Pushed type |
| Line width | 10/15/20/30cm | 15-45cm | 15-45cm | 15-45cm | 45/40cm |
| Bank capacity | 100kg | 75kg | 100kg | 450kg | 65kg |
| Dimensions | 110*88*95cm | 120*90*92cm | 130*90*110cm | 370*160*210cm | 120*80*95cm |
| Weight | 225kg | 230kg | 258kg | 2100kg | 130kg |
Our main thermoplastic road paint preheaters:
| Item | Type | Capacity | Engine |
| OR-XHD-01 | Hydraulic | 450*2=900kg | 15HP |
| OR-XHD-02 | Hydraulic | 500kgs*2=1000kg | 16.5HP |
| OR-XHD-03 | Mechanism | 300*2=600kg | 8.0PS |
| OR-XHS-01 | Mechanism | 300kg | 6.5PS |
| OR-XHS-02 | Hydraulic | 500kg | 6.5PS |
| OR-XHS-03 | Hydraulic | 360kg | 6.5PS |
| Packaging Detail | one layer platic bag; another polybag. So that it will be protected during rainy transportation. | |
| 25kgs/bag; a 20'GP can load 21-25tons of thermoplastic paint. | ||
| Delivery Detail | In 3 working days of 50% down payment receipt | |
Please contact me if any interest!
Zhengzhou Allraise Co., Ltd.
