Help CenterCast Iron Wire Mesh Machine for Aluminum and ss Wire Mesh
Related Products
-
Best Sales Stainless Steel Woven Wedge Wire Frame Screen Machine inUS$ 5,000 - 15,000MOQ: 1 Set -
Stainless Steel Wire Mesh 316 Weaving Machine High SpeedUS$ 5,000 - 15,000MOQ: 1 Set
-
Shuttleless Weaving Wire Mesh Machine for Stainless Steel WireUS$ 5,000 - 15,000MOQ: 1 Set
-
Machine Spare Parts of the Shuttle-less Weaving MachineUS$ 5,000 - 15,000MOQ: 1 Set
-
Vibrating Screen Mesh Machine/scimped Wire Mesh Machine for IndiaUS$ 5,000 - 15,000MOQ: 1 Set
1,Shuttleless weaving machine
Characteristics:1,,Adaptability to metal wires:Adapt to various imported and domestic metal wires.
2,Large adjust range:The metal wire screen can be woven out mesh but also special kinds up to 2600 mesh,such as plain weaving,twill weaving,mat weaving and taper contrast high density screen weaving,etc,and have advantage over products of other machines.
3,The machine adopts technique of shuttless and straightway weft leading,automatic warp feeding and winding.Sheddings are small,and surfaces of woven screens are smooth,and there is not any bright spot,bright trace and other defects on fine screens.The machine can make high-grade in the standard of GB/T 5330-2003.
4,Lower center of gravity,good stability,low noise and energy consumption,high effciency.
5,Rational design,simple construction,easy to operate and maintain.
Item |
Weaving Width (mm) |
Wire Diameter (mm) |
Mesh Size (mm) |
Power (v) |
Weaving Speed (T/Min) |
Weave Type |
Weight (KG) |
Outsize (mm) |
1300B |
1300 |
0.025-0.3 |
40-400 |
380V 2.2KW |
75-78 |
Plain and Twill |
3000 |
2600x2800x1200 |
1300D |
1300 |
0.1-0.4 |
20-80 |
380V 4KW |
53 |
Plain and Twill |
3400 |
2569x3535x1849 |
1300Q |
1300 |
0.1-0.6 |
10-40 |
380V 2.2KW |
53 |
Plain |
3500 |
2569x3535x1849 |
1300QD |
1300 |
0.8-1.6 |
4-40 |
380V 5.5-7.5KW |
53 |
Plain |
9000 |
2600x2800x1200
|
Machine photos
Finished product
Gurantee
We are the number of trade assurance, we have USD36,000 to 100% refund of the Trade Assurance Amount for orders not meeting agreed delivery and quality terms contained in the contract.
