Help CenterBrick Coil Mesh Making Machine
US$ 1,200 - 4,500
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
YHT
Model Number:
Corner angle bead machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Speed Corner Bead Making MachineUS$ 1,200 - 4,500MOQ: 1 Set -
Expanded Reinforcing Mesh Machine for WallUS$ 1,200 - 4,500MOQ: 1 Set
-
Wall Plasterboard Making MachineUS$ 1,200 - 4,500MOQ: 1 Set
-
Automatic Corner Bead Making MachineUS$ 1,200 - 4,500MOQ: 1 Set
-
Expanded Steel Corner Beads MachineUS$ 1,200 - 4,500MOQ: 1 Set
Place of Origin
Hebei, China
Brand Name
YHT
Model Number
Corner angle bead machine
After-sales Service Provided
Engineers available to service machinery overseas
Product Description
Corner angle bead machine
The expanded metal bead production line includes:
1 set of decoiler----1 set of expanded main machine-----1set of profiling machine-----1 set of collecting table-----1 set of PLC controlling cabinet
Specification:
1. Applicable material thickness: 0.2~0.55mm
2. Mesh size (SW*LW): 12mm×25mm,13mm×28mm or at customer's requirement
3. Applicable material: galvanized Iron or CRS or HRS
4. Motor power of decoiler: 1.2KW
5. Motor power of expanded main machine: 3KW
6. Motor power of the profiling machine: 1.5KW
7. Motor power of recoiler:1.2KW
8. Electrical controlling system: PLC
9. Working speed:200 strokes/min
9. Operation space: 15000 mm×1800 mm×2300mm
10. Weight: 10000kg
