3 axle tank trailer for sale
- 1000 Unit / Units per Month
- TIANJIN
- T/T
- Dongfeng Brand Oil Tanker Lorry Petroleum Tanker Truck
- Small Oil Tanker Truck Safe, Reliable And Easy To Drive Oil Tanker Truck For Sale
- Oil Truck Tanker Edible Oil Tanker Truck Large Capacity
- Dongfeng High Quality Buy Oil Tanker Truck Truck Oil Tanker
- Dongfeng Brand Tata Oil Tanker Truck Price Indian Oil Tanker Truck Price
- Semi Trailer Mini Oil Tankers For Sale For Oil/diesel/gasoline Oil Tanker
Product Details
Condition: | New | Storage: | Oil | Drive Wheel: | Other |
Fuel Type: | Diesel | Dimensions (L x W x H) (mm): | 11980MM*2500MM*3800MM | ||
Brand Name: | HUAYUDA | Place of Origin: | Shandong, China | Model Number: | HYD-50000312 |
Gross Vehicle Weight: | 9000 |
Product Description
*Product parameters
Dimension | 12950X2500X3950(mm) |
Kingpin setting | 1350(mm) |
Kingpin plate height | 1310(mm) |
Axle Space | 6650mm+1310mm+1310mm |
Tare weight | 9500kg |
Loading capacity | 40000L |
Lanidng Gear | Tfoc/Jost 28T One-Speed Landing Gear |
Kingpin | Optional for Baohua/Jost 2.0"/3.5" |
Brake system | Dual line pneumatic brake system |
ABS | Yes |
Brake Chamber | Type 30/30 spring brake system on all axles |
Suspension | Spring suspension |
Axle | FUWA/BPW axle, 13 ton capacity/set, 3PCS |
Tire | 11.00R20, 12 PCS |
Rim | 8.0-20, 12PCS |
Tool box | 1PCS |
Spare Tire Carrier | 2PCS |
Compartment | One |
Tank Material | Carbon steel, thickness 5mm |
Bulkhead | Thickness 5mm |
Baffle | Thickness 4mm approx |
Shape of Tank | Ellipse (double "d") |
Test pressure designed | 36kpa |
Fire extinguisher | 2PCS |
Manhole | One |
Discharge hose | 4X6mm |
Hose carries | 2PCS |
*Advantage
1.The semi-trailer utilizes the domestic and international most advances PRO/ENGINEER 3-dimensional design software and the finite element analysis and frame mechanical analysis to guarantee the quality of tank body,improve the safety coefficient during the transport,and maximize the structural rationality of whole vehicle while ensuring that every part is optimized for matching.
2.The raw materials and parts adopt the products from domestic or foreign renowned brands,of which the critical structural parts are specially supplied by the China's biggest special vehicle parts supplier.
3.The tank body is rolled by large rolling machine and one-time two-face special forming welder and special overturning and welding equipment are adopted at the time of welding to ensure fabrication precision.The sealing plug adopts advanced tensioning plug process,featuring more powerful impact resistance.The quality control points are established to implement the quality management measures to each step of the production process and thus effectively guarantee the stability and reliability of the product quality.
4.The sealing test of tanker semitrailer is conducted before the delivery of product to ensure good sealing performance of whole vehicle,without and air leakage or permeation.The special inspection equipment,Xray detector,is utilized to eliminate all potential safety risks of the tank body in the manufacturing process.
5.The value protection box is installed at the material outlet,in order to prevent the leakage of transport medium from causing environment pollution and personal injuries.
6.The suspension system adopts the characteristic new suspension to ensure balance load transmission among various chafts and eliminate any abnormal tire wear.
7.The snap ring for shafts are of integrally cast parts.High attendance rate and low malfunction rate ensure longer effective working time of the vehicle and build higher operation value for the customers.
*Feature
1.Multiple structure and multiple materials of tank body to meet individual loading demands! Choice of multiple models and multiple series and multiple series to meet transport demands of different medium!
2.It's applicable for the transport of all kinds of liquid chemical products,such as diesel,gasoline,caustic soda,concentrated sulfuric acid,and crude oil.The inside of tank body is corrosion
proof treated to meet the transport demands for all kinds of liquid foods and chemical liquids.
3.The tank body is in shape of oval,rounded rectangle,or circle and is designed as per requirements of national standard to improve the operation safety.
4.The OEM parts from domestic and foreign renowned brands are adopted,featuring elegance,durability,and reduction of operation cost and repair cost.
5.The liquid tanker semitrailer obtained multiple national patents,featuring light dead weight and low gravity center of whole vehicle.
6.The traveling mechanism of semitrailer products adopts high strength national standard steel to guarantee the resistance against distortion,vibration,and bump and meet the loading requirements on different roads.
7.The tank body adopts the shot blasting,phosphating,and derusting processes and high grade polyester powder coating,featuring high paint adhesion and elegant,shining ,and lasting performance.
8.The whole vehicle adopts special electric harness with explosion-proof and contamination-proof to guarantee circuit safety.
Transportation
We have cooperated with professional logistics forwarders for years,and with a longterm relationship we can get good O/F price.With experience and professional skills,We will choose the best way to transport cargo to savecost for our customers.
During loading,we take photoes and welcome customers to supervise the loading.We definately can secure the condition of the equipments.
