China Suppliers Marine Single-deck Stainless Steel Navigation Signal Light CXH-1S
The scope of application:
Applied to the ships with the length 50m or above 50m as lamp signal liaision when night navigation.
Product characteristics:
1. The shell adopts good quality stainless steel plate. The surface is painted the special mold-power,
has the feature of corrosion resisting and shock resistance.
2. The signal lights have the shole seal structure, it is waterproof under the bad environmeat.
3. It is convenient to replace the bulb due to the quick-open cover.
4. The lampshade adopts PC material, chroma, stable and ultraviolet radiation resistance.
Production authentication:
Approved by CCS (China Classification Society), and ZY of China Fishery Inspection.
Adopt standard:
1. Conform to THE INTERNATIONAL REGULATIONS FOR PREVENTINGS COLLISION AT SEA,
1972 and GRADE ENTRY NORMS FOR STEEL SHIPS.
2. Conform to the standard of marine electric signal light’s technical condition GB/T 3028-12012.
Voltage | 24V | 110V | 220V |
Power | 60W | 60W | 65W |
Luminous intensity | 60cd | ||
Lamp holder | P28S | ||
Protection class | IP56 | ||
Cable outside Diameter | Ø11 | ||
Name | Model | Visible | Level arc | Color | Weight |
Starboard light | CXH1-1S | 3n.m | 112.5° | Green | 2.2kg |
Port light | CXH2-1S | 3n.m | 112.5° | Red | 2.2kg |
Masthead light | CXH3-1S | 6n.m | 225° | white | 2.1kg |
Stern light | CXH4-1S | 3n.m | 135° | White/Yellow | 2.3kg |
All-round light | CXH6-1S | 3n.m | 360° | Red/Green/white | 2.0kg |
Packaging:
Contact information:
