China Suppliers Marine Single-deck Stainless Steel Navigation Signal Light CXH-2S
The scope of application:
Applied to the ships with the length 12m or above 12m (<50m) as lamp signal liaision when night navigation.
Product characteristics:
1. It is convenient to install and replace the bulb, there are automatic leakage hole at the bottom.
2. The shell adopts stainless steel material, the surface is painted the special mold-powder, has the feature
of corrosion-resisting and shock resistance.
3. The lampshade adopts PC material, it has the feature of ultraviolet radiation resistance and non-discolouring.
Production authentication:
Approved by CCS (China Classification Society), and ZY of China Fishery Inspection.
Adopt standard:
1. Conform to THE INTERNATIONAL REGULATIONS FOR PREVENTINGS COLLISION AT SEA, 1972
and GRADE ENTRY NORMS FOR STEEL SHIPS.
2. Conform to the standard of marine electric signal light’s technical condition GB/T 3028-12012.
Voltage |
24V |
Power |
30W |
Lamp holder |
B15d |
Protection class |
IP56 |
Cable outside Diameter |
Ø8 |
Name |
Model |
Visible |
Level arc |
Color |
Weight |
Starboard light |
CXH1-2S |
2n.m |
112.5° |
Green |
1.5kg |
Port light |
CXH2-2S |
2n.m |
112.5° |
Red |
1.5kg |
Masthead light |
CXH3-2S |
5n.m |
225° |
white |
1.4kg |
Stern light |
CXH4-2S |
2n.m |
135° |
White/Yellow |
1.4kg |
All-round light |
CXH6-2S |
2n.m |
360° |
Red/Green/white |
1.3kg |
